Product Details
| Condition: | New | Type: | Rotary Drilling Rig | Place of Origin: | Henan, China |
| Brand Name: | Hanfa | Model Number: | HF200 | Usage: | Water Well |
Product Description
Specifications
drilling machine1.wheels, easy to move
2.diesel engine/electric motor
3.multi-functional
4.hydraulic automatic feeding
HF200 drilling machine with drilling depth 200m, drilling diameter30-20mm
I.Introduction of drilling machine HF200
>it can drill Max200m depth,Max 500mm drill diameter
II. Technical parameter of drilling machine HF200
Main machine technical parameter | |||
Drilling depth | 200m | ||
Drlling diameter | 300mm | ||
End diameter | 75mm | ||
Drilling pipe diameter | 50mm | ||
Drilling angle | 90°~75° | ||
Drilling weight(no include power) | 975kg | ||
Unity machine dimesions | 2.75×0.95×1.6m | ||
Spindle | |||
Spindle speed | 64,128,287,557r/min | ||
Spindle stroke | 450mm | ||
Hoist | |||
Max.single line hoisting capacity | 2400kg | ||
Reel lifting speed | 17,35,75,151r/min | ||
Reel diameter | 140mm | ||
Wirerope diameter | 13mm | ||
Wirerop cubic measure | 35m | ||
Hug floodgate diameter | 260mm | ||
Hug floodgate belt width | 70mm | ||
Distance between drill and hole | 400mm | ||
Power | |||
Diesel engine | s1105 Model, 22HP | ||
Electric Motor | Y160M—4 ,15kw 1440r/min | ||
Mud pump | |||
Type | Horizontal single urn twin-action | ||
Displacement | 170L/min | ||
Maximum pressure | 3.0Mpa | ||
Work pressure | 1.5Mpa | ||
Water inlet caliber | 40mm | ||
Water to exit caliber | 30mm | ||
Triangle conveyer belt | B1728mm | ||
Hydraulic pump | |||
specification | CBT—F—314 | ||
Triangle conveyer belt | B1100×1 | ||
Useful | |||
Geology general check exploration,Earth physics exploration,Road and high layer building ground survey,water Well,Blast opening etc drilling engineering | |||
