Hard Rock Driller! HF200 Water Drilling Rig Machine

US$ 1 - 12,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Rotary Drilling Rig

Power Type:

Diesel

Zhengzhou Hanfa Prospecting Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Rotary Drilling Rig

Power Type Diesel

Place of Origin Henan, China

Brand Name HF

Model Number HF200

Usage Water Well

Dimension(L*W*H) 2.1*0.9*1.3m

Weight 150KG

Certification ISO

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

Specifications

HF200 water drilling rig machine
1.200m Depth
2.hydraulic&trailer mounted
3.for complex stratums
4.easy to operate

Hard Rock Driller! HF200 Rock Core Sampling Drilling Rigs for sale

1,53X59 driving lever is adopted ,high rigitidy,strong delivery torque

2,This machine adopts national patent technology taper clutch,with charactristics of strong transmission torque,

easy opeation,free maintenance

3,Hoist planetary gear module and the installation of supporting frames greatly increasing the upgrading and braking

ability of the hoist

4,Vertical box four couple of bearings positioned to ensure the rotary machine has a sufficient rigid response to

gravel layer,the comples geolohical conditions

5,We are the first one to equip mud pump with the flow 160L/min,with characteristics of saving cost ,compact,mobile,

light weight

Model			HF200
Drilling depth		200m
Drlling diameter		300mm
End diameter		75mm
Drilling pipe diameter		50mm
Drilling angle		90°~75°
Drilling weight(no include power)		1050kg
Unity machine dimesions		2.1×0.9×1.3m
Spindle
Spindle speed		64,128,287,557r/min
Spindle stroke		450mm
Hoist
Max.single line hoisting capacity				2400kg
Reel lifting speed		17,35,75,151r/min
Reel diameter		140mm
Wirerope diameter		13mm
Wirerop cubic measure		35m
Hug floodgate diameter		260mm
Hug floodgate belt width		70mm
Distance between drill and hole		400mm
Power
Diesel engine		s1105 Model, 22HP
Electric Motor		Y160M—4 ,15kw 1440r/min
Mud pump
Type	Horizontal single urn twin-action
Displacement	170L/min
Maximum pressure	3.0Mpa
Work pressure	1.5Mpa
Water inlet caliber	40mm
Water to exit caliber	30mm
Triangle conveyer belt	B1728mm
Hydraulic pump
specification	CBT—F—314
Triangle conveyer belt	B1100×1
Useful
Geology general check exploration,Earth physics exploration,sampling test in mining, water Well ,Geothermal ,Blast opening etc drilling engineering
