HF-8 Mine Exploration Drill Rig, Deep Water Drilling Rig

HF-8 Mine Exploration Drill Rig, Deep Water Drilling Rig thumbnail-1
HF-8 Mine Exploration Drill Rig, Deep Water Drilling Rig photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Zhengzhou Hanfa Prospecting Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Rotary Drilling Rig
Power Type Diesel
Place of Origin Henan, China
Brand Name Hanfa
Model Number HF-8B
Usage Coal
After-sales Service Provided Engineers available to service machinery overseas

Specifications

HF-8 mine exploration drill rig from Hafan company
1. thousand meter drill rig
2. deep water drill rig

HF-8 mine exploration drill rig from Hafan company

1. thousand meter drill rig
2. deep water drill rig



HF-8 mine exploration drill rig, deep water drilling rig



HF-8 mine exploration drill rig, deep water drilling rigHF-8 mine exploration drill rig, deep water drilling rig

HF-8 mine exploration drill rig, deep water drilling rig

HF-8 mine exploration drill rig, deep water drilling rigHF-8 mine exploration drill rig, deep water drilling rig



2 Drilling Angel----------------------------------------------0~360°







3 Power Unit



   Electric Motor   Y280S-4               75KW         1480rpm



  Diesel engine   YC6A240-33           177KW         2300rpm







4 Rotator



  Type:Feeding with double oil cylinders hydraulic pressure.Cylinder diameter:100mm.



   Spindle I.D----------------------------------------------96mm







Spindle Rotation Speed



   With electric motor(1480rpm):



   Forward Speed:74; 106; 150; 208; 300; 431; 609; 845   rpm



   Reserve Speed:74rpm







With diesel engine(2300rpm):



   Forward Speed:110; 157; 222; 309; 445; 640; 905; 1256  rpm



   Reserve Speed:110rpm







  Max.Torque of spindle------------------------------------8000Nm



  Spindle stroke-----------------------------------------------800mm



  Max.lifting force of spindle-------------------------------180KN



  Max.thrust of spindle--------------------------------------110KN







5  Winch



   Type:Planetary gear drive, hand brake.



   Wire rope caliber---------------------------------------------21.5mm(6X19)



   Drum capacity for rope-------------------------------------120m



   Max.lifting force(single rope)------------------------------60KN







   Lifting speed of the wirerope



   Power unit rotary speed 1480rpm:0.48; 0.68;0.96;1.34;1.96; 2.81;3.96;5.51m/s



   Power unit rotary speed 2300rpm: 0.71; 1.01; 1.42; 1.99; 2.91;4.17;5.88;  8.19m/s







6. Transmission:Shanxi Fast Gear 8JS118 transmission and ancillary clutch, safe and reliable.







7. Oil Pump



   Type:gear oil pump    Model:CB-32



   Rotary speed-----------------------------------------------2500r/min



   Displacement-----------------------------------------------32 ml/r



   Work pressure----------------------------------------------20Mpa



   ure-----------------------------------------------25Mpa



   Direction of rotation----------------------------------------Right(see from shaft end)







8. Water brake



   Work rotary speed-----------------------------------------700—1800r/min



   Single rope compensational speed--------------------3—8m/s



   Single rope compensational load----------------------45KN







9. Drill Fram



   Form:skids type(with sliding base)



   Rig backward stroke--------------------------------------530mm







10. Dimensions(LXWXH)--------------------------------3800X1500X2460mm







11. Rig weight----------------------------------------------------6500Kg



HF-8 mine exploration drill rig, deep water drilling rig

HF-8 mine exploration drill rig, deep water drilling rigHF-8 mine exploration drill rig, deep water drilling rig
