Help CenterZKL-30 Track Type Long Screw Drilling Machine
Related Products
-
ZKL-30 Track Type Long Screw Drilling RigNegotiableMOQ: 1 Set -
Caterlillar Type Long Screw Drilling Rig ZKL-30NegotiableMOQ: 1 Set
-
New Product~KP2200 Type Engineering Drilling MachineUS$ 79,000 - 110,000MOQ: 1 Set
-
KP2000 Professional Engineering Drilling RigUS$ 1 - 69,000MOQ: 1 Set
-
KP3500 Full Hydraulic Pressure Rotary Mode Drilling MachineNegotiableMOQ: 1 Set
Specifications
electrohydraulic concentrative control, with convennience for operationThe drilling rig is a kind of deep drilling long screw drilling machine newly reseached and developed by the company. The pile holder of this drilling machine applies ship like track, caterpillar type travel, with flexible displacement and convenient emplacement. The drilling machine applies electrohydraulic concentrative control, with convennience for operation, and the three-point support upright post that can be adjusted at the back and forth or on the left and right. The complete machine can realize the 360° . Full revolution. The part of drilling tools apply three ring decelerator for power, key type flange as drill rod, being safe, reliable, and shortcut dismantling. The drilling machine can be equipped with construction techniques such as ultra flow form, high pressure slurry filling and dry method pore forming; The pile holder can be equipped with the vibratory hammer below 120kw. It can realize the construction of premoulded pile, concrete influx pile, concre te garlic pile, lime pile, gravel pile, etc.
If used for drilling influx pile operation, the ZKL-30 Type hydraulic caterpillar type machine has high pore forming efficiency, good quality, mo shock, noise or pollution, and high degree of mechanization; Better performance than hammering and pile sinking methods for penetrating the sand and gravel layers, at the same time, it avoids the adverse effect on the adejacent buildings due to the hammering and vibration pile sinking's press on foundation. Therefore, this drilling machine, as a kind of environmental-friendly piling mechanical product specially applicable to urban construntion, is broadly applied to the pile foundation construction of industrial and civil buidings.
| Model | ZKL-30 | ||
| Hole diameter(mm) | 400 600 | 800 | |
| Drilling depth (m) | 30 | 25 | |
| Power unit | Power(kw) | 55*2 | |
| Rotation(r/min) | 24.2 | ||
| Torque(KN. m) | 48 | ||
| Allowable drill drawingout force( KN) | 400 | ||
| Pile holder Mass(t) | 60 | ||
| The inclination range of upright post | 12 degrees ahead and 3 degrees back | ||
| Contact area pressure ratio (MPa) | 0.045-0.35 | ||
| Travel speed(m/min) | 4.5 | ||
| Step lengh(m) | 3 | ||
| The max allowable slope angle (degree) | 2 degrees | ||
| Working external dimensions (m) | 13.5*6*36 | ||
| Can be equipped with vibratory | |||
| Hammer multishaft type continuous | |||
| wall drilling machine | Below 120kw | ||
