Product Details
| Condition: | New | Type: | Other, DTH drilling rig | Power Type: | Diesel |
| Place of Origin: | Henan, China | Brand Name: | Hanfa percussion rotary air blast drilling | Model Number: | HF130Y percussion rotary air blast drilling |
| Usage: | Other, blasing holes,anchoring,open mining | Power(W): | 45KW | Dimension(L*W*H): | 5200*2030*2300 |
| Weight: | 3800kg | Certification: | ISO,CE | Warranty: | one year quality warranty |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Open mines! low air consumption! HF138Y percussion rotary air blast drilling
Specifications
HF138Y type crawler hydraulic drilling rig, using a new hydraulic technology, with low air consumption rotary torque, variablebit shift hole easy
The drilling rig compact structure, while promoting a retractable sliding shelf compensation, drilling when the
sliding frame support on the ground, drilling and good stability. Use HF138Y rig reliable Chazzan efficient drilling in hard rock drilling rig
as fast as 2 times the low air pressure is the construction unit cost efficiency gains strong support.
The drilling rig is mainly suitable for open mining, water conservancy, power plants, road building and other Rock blasting whole drilling.
Technical Parameters:
Main technical parameters | |
Wind pressure (Mpa) | 0.7----1.6 |
Air consumption (m³/min) | 10----15 |
Drilling diameter (mm) | 90----130((max:203) |
Drilling depth (m) | level 40m,down 80m |
Once promotion distance (mm) | 3000 |
Drill diameter (mm) | 60 |
Skid compensation (mm) | 900 |
Maximum lift force (N) | 24900 |
Skid pitch (°) | up and down total 95 |
Swinging angle of skid (°) | Left 38, right 31 |
Boom Pitch (°) | up and down total 70 |
Boom swing angle (°) | Left 41, right 33 |
Grade ability (°) | 30 |
Chassis ground clearance (mm) | 260 |
Travelling speed (km/h) | 2 |
Back to the transit speed (r/min) | 0----80 |
Rotary torque (N.m) | 2000 |
Host Power (Kw) | 45 |
For rock (f) | 6----20 |
Impact frequency (r/min) | 950---1500 |
Total Weight (kg) | 3800 |
Dimension (L * W * H) | 5200*2030*2300 |
Note: The Company’s products continued to improve; various design and technical specifications may change at any time, without any additional notice or obligation.
