Specifications
HF-15 gold core drilling rig1.15m depth,46/60mm diameter
2.power:gasoline engine
3.small volume,light weight
small volume, easy operate HF-15 portable gold core drilling rig
Brief introduction
HF-15 portable sampling drill is a kind of full-automatic sampling drill which combines various drill features and is improved all the time. The power source
of the drill is gasoline engine, its rewinding is driven by hydraulic pressure,
then the cylinder adds pressure to satisfy large range of load change and
reliable running.
According to various geological conditions, you can choose diamond, alloy or
steel particles drilling bit for drilling. You can also practice drill pile feeding as
non-stop then the efficiency will be high. Centralized handles make operation
easy. Compact structure, small volume, light weight, easy to disassemble and
move lets it fit to work in flat and mountain areas. Its reliable function, complete
coring and flexible operation are fit for field work, then improve the efficiency and decrease the sampling cost, which has reached international advanced grade;
Applications
HF-15 portable sampling drill is mainly used in drilling and borehole sampling projects like geochemical prospecting & sampling, aerial geological mapping, ore vein survey in shallow surface and sap, geophysical prospecting epicenter hole construction, geotechnical engineering and so on.
Main features
(1) Employ gasoline engine as power, fit for sampling & drilling as no power outside;
(2) Rewinding driven by hydraulic pressure, meet loading change in a large range, reliable running;
(3) Smart and light, good disorganization, move easily, fit for wild field long distance traveling;
(4) Simple operation, easy to study and master, practical and reliable.
drilling mode |
rewinding then cutting in high speed |
circulation medium |
water, mud |
Hole termination diameter |
46,60mm |
|
max drilling depth |
15m |
Power |
14 HP |
Power unit rotation speed |
300-1000 r/min |
|
Motor travel distance |
1100mm |
|
Hydraulic system rated pressure |
14Mpa |
Tower frame |
triangle, height: 1.6m |
|
max. single weight |
60kg |
Total weight of the rig |
170kg |
