Home > Manufacturing & Processing Machinery > Drilling Rig > Mine Drilling Rig > Easy Operation,trailer Mounted Type , HF-3 Multi-functional Deep Water Well Drilling Rig

Easy Operation,trailer Mounted Type , HF-3 Multi-functional Deep Water Well Drilling Rig

US$ 1 - 35,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Rotary Drilling Rig

Place of Origin:

Henan, China

Contact Supplier Request Quote Chat Now

Zhengzhou Hanfa Prospecting Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Rotary Drilling Rig

Place of Origin Henan, China

Brand Name HF

Model Number HF-3

Usage Water Well

After-sales Service Provided Overseas third-party support available

Specifications

HF-3 deep water well drilling rig
1.hydraulic control
2.drill hard rock
3.trailer mounted
4.600m depth

Trailer mounted and hydraulic control~ HF-3 multi-functional deep well drilling rig

1. HF-3 drilling rig can drill 300-600m depth, 300-75mm hole diameter.

2. Strong ability for drilling clay,sand,soil,gravel,hard rock and other complex geology conditions.

3. Hydraulic machine, very capable and easy to operate.Trailer type with 6 wheels, can be dragged by vehicles, very convenient for moving and transportation.

4. Equiped with 50HP diesel engine, very powerful for drilling and convenient for using in the place with no electricity.

5.it can be used for drilling water well,geothermy well,soil sampling or mining sampling,geological prospecting etc,wide application

HF-3 water well drilling machine technical data

Drilling depth	m	300-600
Open hole caliber	mm	300
End hole caliber	mm	75
Drilling rod	mm	60
Drilling angle		90°-65°
Spindle
Spindle forward speed	r/min	57-1024
Spindle reverse speed	r/min	45-212
Spindle stroke	mm	560
Spindle inner diameter	mm	96
Spindle lifting capacity	KG	6000
Hoist
Single line lifting speed	m/s	0.515 0.894 1.421 1.948
Hug floodgate belt width	mm	90
Tightrope caliber	mm	12.5 or 14
Hoist single line lifting capacity	KG	3000
Reel caliber	mm	200
Reel cubic measure	m	30
Mud pump
Horizontal double actuator
Displacement	L/min	200,125
Triangle conveyer belt type		B×5
Work pressure	Mpa	4.6
Water inlet caliber	mm	65
Water to exit caliber	mm	37
Oil pump
Duplex gear oil pump F532/F314
Front displacement,pressure		32L/min 20Mpa
Behind displacement,pressure		14L/min 20Mpa
Drilling rig Power
Diesel engine	Hp	395Kz 27HP
Electric motor	KW	Y180L-4 22KW
