Woltman Type Digital Water Meter

Specifications

Woltman Type Digital Water Meter
1, Dry-dial, Detachable.
2,Digital Water Flow Meter
3,Conform to Class B, ISO4064

            Woltman Type Digital Water Meter











APPLICATION:
The range of water meter is used to measure the total quantity of cold/hot water which was

consumed in industrial and mining enterprise passing through the pipeline.





FEATURES:

--Removable element structure, easy installation and maintenance, register for universal use

    within this range detachable without Removing the meter from the pipeline;



--Dry-dial, Magnetic drive sensitive action, small pressure loss;



--Vacuum sealed register ensures the dial keep free from fog and Keep the reading clear in a

    long term service;



--Selected high quality materials for steady & reliable characteristic;



--Technical data conform to international standard ISO 4064.

WORKING CONDITION:
Water temperature: ≤40°C  Water pressure: ≤1.0MPa (1.6MPa for option)

COMPLIANCE WITH STANDARD: ISO 4064 (GB/T778-1996)



Maximum permissible error:

(1) in the lower zone from q_min inclusive up to but excluding q_t is ±5%.

(2) in the upper zone from q_t inclusive up to and including q_s is ±2%;



Dimensions
