2015 high sale Double roller crusher, 2-roller crusher, China famous brand!
1.Professional design
2.8 years experience
3.high technology 2-roller crusher
2015 high sale Double roller crusher, 2-roller crusher, China famous brand!
1. Introduction
2-Roller Crusher is widely applied in the industries of mining, building materials, chemical industry, metallurgy, etc. Slag Cement Hydraulic Roll Crusher can crush materials with middle hardness or less than middle hardness into secondary or fine granularity, such as crushing mineral, rocks, coke, coal, slag, scoria, and fire-proof material etc.
2. Main Applications
Mainly used for the crushing of medium or lower-hardness mines and rocks with medium or lower rigidity in mine selection, chemicals, cement and building materials industrial production.
3. Working Principle
The fixed part of roller and movable roller are driven by the motor via reducer and v-belt, the raw materials fall into the part between the two rollers from inlet of the machine. The two rollers rotates inward simultaneously. The materials are extruded, crushed and ground, then the end products come out from the bottom of this crusher.
Main technical parameters
| Certification and type |
Material-in size (mm) |
Material-out size (mm) |
Capacity (t/h) |
Motor power (kw) |
Weight (kg) |
| 2PG-400x250 | <25 | 1-8 | 5-10 | 11 | 1500 |
| 2PG-500x400 | <30 | 1-10 | 8-20 |
22 | 3200 |
| 2PG-610x400 | <40 | 1-20 | 13-35 | 30 | 4500 |
| 2PG-610x800 | <40 | 1-20 | 15-40 | 37 | 12250 |
| 2PG-750x500 | <45 | 1-20 | 15-40 | 37 | 12250 |
| 2PG-750x700 | <45 | 1-20 | 20-50 | 44 | 14000 |
| 2PG-900x500 | <55 | 1-40 | 20-50 | 44 | 14000 |
| 2PG-900x900 | <55 | 1-50 | 20-70 | 37x2 | 16800 |
| 2PG-900x1200 | <55 | 1-50 | 25-90 | 55x2 | 20800 |
| 2PG-1200x1000 | <70 | 1-60 | 25-100 | 45x2 | 40200 |
| 2PG-1200x1200 | <70 | 1-60 | 30-120 | 75x2 | 41980 |
1. Pre-sale support
l Huahong Machinery consists of experienced specialists, we will offer a suitable solution according client’s requirement in time.
l On-site inspection
2. After-sale service
.Huahong's skilled technicians are available to assist with onsite installation, commissioning & training on request. This will enable customers to optimize the performance of their new plant. Customers will be briefed on all aspects relating to operation and maintenance by a Huahong technician. Dimensional drawings together with service requirements will be provided prior to delivery of the equipment. This will allow the customer to prepare the site and allow them to commence production in a timely fashion.
l Huahong holds a adequately inventory of spare parts and their efficient service personnel will ensure that any required part will be dispatched without delay. Delivery of the spare parts may be by air, sea or courier depending on the urgency of the situation. Customers are encouraged to hold their own critical spare parts such as granulator blades and screens to ensure optimal machine condition and performance.
3. Technical support
l Huahong provides enough hardware resource especially for large-scale production lines, clients can carry out installation, commissioning and acceptance before delivery.
l Regular return visit
Zhengzhou Huahong Machinery Equipment Co., Ltd. is located in Zhengzhou National Hi-Tech Industrial Development Zone, Henan Province. Our company has passed ISO9001 international quality system certification. Our company has two industrial plants of 10,000 square meters and we have 200 sets of large and medium-sized processing, welding and assembly equipment, with the maximum lifting capacity of 150 tons. Our company mainly produces all kinds of jaw crushers, impact crushers, cone crushers, hammer crushers, Raymond mills,
