Specifications
DI, Ductile Iron Mechanical Joint Pipe1. ISO2531&EN545 certificated by SGS
2. DN80-DN2600
3. T-type K9
4. Bitumen Coat
DI, Ductile Iron Mechanical Joint Pipe
- ISO2531&EN545 ductile iron pipe certified by SGS
- Size range: DN80-DN2600
- Mechanical joint K9 Class
- Effective length: 6m or 5.5m
- Gasket: EPDM or SBR
- Outside coating: zinc painting+bituminous painting or epoxy coating
- Inside lining: cement mortar lining or high alumina cement mortar lining
- Suitable for water distribution
Specifications of ductile iron pipes we supply:
1) Standard: ISO2531, BSEN545 or EN598
2) Effective length: 6m ,5.7m, 5.5m
3) Inner cement: Ordinary portland cement according to ISO4179, sulphate resistant cement
or
high alumina cement mortar lining
4) Outside coating: Zinc coating(≥130/m2) and bitumen paiting or epoxy paiting(≥70μm)
according to ISO8179
5) Quality Control:Matallqgraphic examination;Spectrum Analysis;Hardness Test;
Tensile Test;Crush Test.
6) Diameter: DN80- DN2600mm
7) Joint type: Mechanical joint
8) High strength ,lighter than gray iron,good corrosion resistance,no furring,small flow
resistance,easy fixing,long life time
9) Testing: factory inspection report, SGS inspection and the third inspection party;
10) Class: K9, K12
11)Packing:DN100-DN300: in bundles; DN350-DN2600: in bulk ship
12) Gasket: EPDM or SBR
Factory Gallery
If you are interested in any of our products, please feel free to contact us.
