Product introduction
Spiral chutes are gravity concentrators and separate minerals of different specific gravity according to their relative movement in response to gravity, centrifugal force and other forces in the fluid medium. It has extremely good performance and effects in processing placer of beach, riverside, seashore and stream.
Spiral chutes are made of polyurethane lined fiberglass with wear-resistant corundum inner surface.
Specifications
1.high quality
2.high recovery ratio
3.separating alluvial gold,zircon,Iron ore, mineral sand, ilmenite
Spiral chute — Product advantages
1.Less floor space; easy and stable operation; rational configuration; convenient installation
2.High processing capacity and efficiency
3.Moisture proof, antirust, corrosion resistant, adaptive, noiseless.
Spiral chute— Product feature
Spiral chute (glass fiber reinforced plastics spiral chute) present advantages as follows: less floor space; easy and stable operation; rational configuration; convenient installation; high processing capacity and efficiency; moisture proof; antirust; corrosion resistant; adaptive and noiseless, etc.
Spiral chute — Product application
Spiral chute (glass fiber reinforced plastics spiral chute) is applicable to metal and non-metal ores with adequate density difference, like iron, chromite, pyrite, tin ore, tungsten, tantalum, niobium, gold ore, colliery, monazite, rutile and Zirconium.
Customer order equipment in Pakistan
Main Thchnical Parameters
Model |
5LL-2000 |
5LL-1500 |
5LL-1200 |
5LL-900 |
5LL-600 |
||
Spiral diameter(mm) |
2000 |
1500 |
1200 |
900 |
600 |
||
Spiral pitch(mm) |
1200 |
720/540 |
720/540 |
675/540 |
450/360 |
||
Max spiral start |
3 |
4 |
4 |
4 |
3 |
||
Max turn each start |
4 |
5 |
5 |
5 |
5 |
||
Feeding particle size(mm) |
4-0.04 |
0.8-0.037 |
0.3-0.03 |
0.3-0.03 |
0.2-0.02 |
||
Feeding density(%) |
20-45 |
25-50 |
25-55 |
25-55 |
25-55 |
||
Capacity(t/h) |
15-40 |
6-8 |
4-6 |
2-3 |
0.8-1.2 |
||
|
Outline size
|
L(mm) |
2300 |
1560 |
1360 |
1060 |
700 |
|
W(mm) |
2300 |
1560 |
1360 |
1060 |
700 |
||
H(mm) |
6500 |
5230 |
5230 |
4000 |
2600 |
||
Weight (kg) |
900 |
800 |
600 |
400 |
150 |
||
Q: Can I visit your factory?
A: Yes. Many domestic and international customers visit our factory every year.
Q: How long is the warranty of your equipment? Do you supply spare parts?
A: Our warranty period is one year generally. We can supply spare parts.
Q: Do you provide after-sale service?
A: Yes. We have a professional after sale service team to promptly and thoroughly solve your problems.
Q: Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training.
After-sales service
(1) During the installation and commissioning, we shall send our technician to the site for guiding the installationand commissioning. and we also offer training service.
(2) If the equipments appear the equipment failure because of improper handling of user, we are in charge of maintenance, and collect the appropriate cost.
(3) We offer the components with favorable price, perdurable maintenance. After quality assurance date, if the equipments need to be repaired, we only collect the cost price.
deliver goods
If you are interested in our products or need more detail information, please don't hesitate to contact us !!!
