Mining equipment spiral chute/mining spiral chute/mining chute machine with factory price
Product introduction
Spiral chutes are gravity concentrators and separate minerals of different specific gravity according to their relative movement in response to gravity, centrifugal force and other forces in the fluid medium. It has extremely good performance and effects in processing placer of beach, riverside, seashore and stream.
Spiral chutes are made of polyurethane lined fiberglass with wear-resistant corundum inner surface.
Specifications
1.high quality
2.high recovery ratio
3.separating alluvial gold,zircon,Iron ore, mineral sand, ilmenite
Spiral chute — Product advantages
1.Less floor space; easy and stable operation; rational configuration; convenient installation
2.High processing capacity and efficiency
3.Moisture proof, antirust, corrosion resistant, adaptive, noiseless.
Spiral chute — Product feature
Spiral chute (glass fiber reinforced plastics spiral chute) present advantages as follows: less floor space; easy and stable operation; rational configuration; convenient installation; high processing capacity and efficiency; moisture proof; antirust; corrosion resistant; adaptive and noiseless, etc.
Spiral chute — Product application
Spiral chute (glass fiber reinforced plastics spiral chute) is applicable to metal and non-metal ores with adequate density difference, like iron, chromite, pyrite, tin ore, tungsten, tantalum, niobium, gold ore, colliery, monazite, rutile and Zirconium.
Main Thchnical Parameters
Model |
5LL-2000 |
5LL-1500 |
5LL-1200 |
5LL-900 |
5LL-600 |
||
Spiral diameter(mm) |
2000 |
1500 |
1200 |
900 |
600 |
||
Spiral pitch(mm) |
1200 |
720/540 |
720/540 |
675/540 |
450/360 |
||
Max spiral start |
3 |
4 |
4 |
4 |
3 |
||
Max turn each start |
4 |
5 |
5 |
5 |
5 |
||
Feeding particle size(mm) |
4-0.04 |
0.8-0.037 |
0.3-0.03 |
0.3-0.03 |
0.2-0.02 |
||
Feeding density(%) |
20-45 |
25-50 |
25-55 |
25-55 |
25-55 |
||
Capacity(t/h) |
15-40 |
6-8 |
4-6 |
2-3 |
0.8-1.2 |
||
|
Outline size
|
L(mm) |
2300 |
1560 |
1360 |
1060 |
700 |
|
W(mm) |
2300 |
1560 |
1360 |
1060 |
700 |
||
H(mm) |
6500 |
5230 |
5230 |
4000 |
2600 |
||
Weight (kg) |
900 |
800 |
600 |
400 |
150 |
||
Looking forward to cooperation with you!!!
