Usage & Application:
sand maker is widely used in fine crushing the granite, basalt, limestone, river gravel, cement clinker, quartz, iron ore, bauxite and other minerals. Meanwhile it is the key equipment for producing quality stone in artificial sand, highway, railway, water conservancy, airport, construction, cement, refractory and metallurgical.
Features
1. Excellent performance and high final fineness.
2. Safe and user-friendly.
3. Smooth and quiet operation.
4. Minimum maintenance.
5.Long service life.
6standard replacement parts.
7.High productivity.
8. Cost effective.
Working principle
The entire center feeding: Material falls into the feed hopper, then enters the high-speed rotary sling wheel from center feeding hole, which is speeded immediately in the sling wheel. The speed can reach several dozens times of the gravity acceleration. Then it is thrown out from the sling wheel. First, it is crushed with other rebounded material fell freely from the sling wheel. Then both of them are impacted to the material lining(rock-rock) or strike back block(rock-iron), rebounded and stroke to the top of eddy cavity in the inclined-up direction. Then it moves along deflection- down, and forms a continuous material curtain with the material from the impellers passage. Just like this,the material is stroke, rubbed, crushed twice or more, then is discharged from the down discharged hole.
Specification of china mine sand making machinery
Model |
Input size (mm) |
Max.Feed Size (mm) |
Setting Adjustment Range(mm) |
Output Size (mm) |
Capacity (t/h) |
Power (kw) |
PX0808 |
800×300 |
160 |
5-20 |
<5 |
30-40 |
55 |
PX1010 |
1000×350 |
180 |
5-20 |
<5 |
40-60 |
90 |
PX1012 |
1200×400 |
180 |
5-20 |
<5 |
70-100 |
110 |
PX1212 |
1200×450 |
180 |
5-20 |
<5 |
80-120 |
132 |
PX1214 |
1500×450 |
190 |
5-20 |
<5 |
100-140 |
160 |
PX1414 |
1500×500 |
190 |
5-20 |
<5 |
120-180 |
200 |
PX1616 |
1600×550 |
200 |
5-20 |
<5 |
170-210 |
250 |
PX1818 |
1800×800 |
200 |
5-20 |
<5 |
250-270 |
315 |
Welcome to inquiry ! ! !
