Specifications
1.feeding grain of large2.out material grain of small
3.Low noise
4.finished rate high
2014 China export high quality sand making machine
Sand making machine feature :
1.Small discharge particle size, uniform grain shape,
2.large capacity and long life of hammer head, small power, variable tertiary crushing for the secondary crushing,
cess simplification, simple structure, convenient maintenance, stable operation, etc.
Advantage and application:
1.Equipment investment is lower35%-50% than the same size of the traditional craft equipment,
2.Output efficiency is higher 35%-50% than the same size of traditional craft equipment.
3.The long-term maintenance cost lower 35%-50%than running the same size of the traditional craft equipment, 4.Widely used in the mechanism of sand production line, cement, refractories, metallurgy and other industries.
PXJ Sand making machine Technical Parameters:
|
Rotor dia*width (mm) |
Input opening size (mm)
|
Feed size (mm) |
Discharge size (mm) |
Output opening range(mm) |
Capacity(T/h) |
Power (kw) |
|
Cement, grog |
limestone |
||||||
Ø800×400 |
400×185 |
<120 |
<5 |
5-20 |
20-30 |
35-45 |
37-45 |
Ø800×600 |
500×250 |
<180 |
<5 |
5-20 |
35-40 |
45-55 |
45-55 |
Ø800×800 |
550×330 |
<180 |
<5 |
5-20 |
35-45 |
55-65 |
45-55 |
Ø1000×1000 |
1000×350 |
<180 |
<5 |
5-20 |
45-55 |
65-75 |
55-75 |
Ø1200×1000 |
1200×400 |
<180 |
<5 |
5-20 |
55-80 |
75-100 |
100-110 |
Ø1200×1200 |
1200×450 |
<180 |
<5 |
5-20 |
75--90 |
90-100 |
100-132 |
Ø1400×1400 |
1500×500 |
<190 |
<5 |
5-20 |
90--130 |
100-150 |
160 |
Ø1600×1600 |
1600×550 |
<190 |
<5 |
5-20 |
170-210 |
190-250 |
250 |
Ø1800×1800 |
1800×800 |
<190 |
<5 |
5-20 |
250-270 |
280-310 |
315 |
Pre-sale services: enthusiasm
We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand
Sale services: servant
Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
After-sale services: faithfulness
To establish long term friendship, we will regularly pay return visit to cust.
1.Which kind of material you are going to use
2.What's the way-in size of sand making machine do you want ?
