Specifications
disc type granulation machine1, production capacity 4~24 t/h
2, rotation speed 9.1~14.25 r/min
3, high efficiency
4, eas
Popular organic Fertilizer Disc Granulating Machine/ machine for making organic fertilizer granules
Round disk granulating machine is a cubage measuring feeding equipment; it supplies materials to the next procedure evenly and continuously; at the same time, it can bear relatively higher pressure.
Hot sale round disk granulating machine is a fine powdery material feeder suitable for non-cohesive materials like coal powder, cement, chamotte, limestone, shale, gangue and clunch. It is widely used in gold concentrator, coal mine, chemical plant, construction and foundry for quantitative and even feeding.
Working principle
Its working principle: this series of products by the main motor drive pulley and belt, through the reducer drive pinion, pinion interlocking with big gear which fixed in the bottom, work oppsite. Big gear with special reasonable design, installed on the main shaft fixed on the frame to adjust plate, to support the work of the granulating disc (this machine is used to spray machine).The material enter the granulating disc,after continuing rotation of the granulating disc and spray device, material sticking evenly to be particles together. In this machine granulation upper plate has design of the automatic cleaning device, preventing the of wall material viscosity, thus greatly improving the service life of the machine. With the constant rotation of motor, materials into unceasingly, can realize the mass production, has reached to the needs of the user.
Usage
Organic fertilizer granulation use organic sludge, chicken manure, straw after fermentation as raw materials.
1Mixed feed granulation With corn flour, grass meal, soybean meal as raw material
2Deodorization sterile efficient fertilizer with livestock and poultry manure, city life garbage by microbial fermentation technology
3Granulating disc granulator can be applied to crude fibre granulation, rice husk, cotton seed, construction waste, etc.
4Granulating disc is widely used in transporting powdery, beaded or small state of all kinds of viscous material, such as coal, cement, clinker, fertilizer and other materials.
Main Technical Parameters:
Type(m) |
Speed of disk |
capacity(t/h) |
power(kw) |
Adjustable Scope |
Size m) |
weight(kg) |
Φ2.2 |
14.25 |
4-8 |
7.5 |
35-55 |
2.8×2.75×2.58 |
2850 |
Φ2.5 |
11.81 |
5-10 |
7.5 |
35-55 |
3.2×2.3×3 |
3250 |
Φ2.8 |
1.21 |
12-16 |
7.5 |
35-55 |
3.4×2.6×3.1 |
3710 |
Φ3.0 |
11.3 |
15-18 |
11 |
35-55 |
3.7×2.7×3.3 |
4350 |
Φ3.2 |
9.6 |
15-20 |
11 |
35-55 |
3.9×2.7×3.4 |
5110 |
Φ3.6 |
9.1 |
18-24 |
15 |
35-55 |
4.3×3.1×4.0 |
6510 |
