Solid Float Rubber Boom is an important equipment that was adapted for use on the sea or other water to control oil spill.Solid Float Rubber Boom:
Description:
Oil boom is an important equipment that was adapted for use on the sea or other water to control oil spill. It is specially adapted for permanent installation on open seas, bays, harbors and docks. It can be used in oil spill response.
The rubber boom is made of double strength synthetic fiber cloth which is covered with good quality synthetic rubber. It is oil-resisting, wear-resisting, seawater-resisting, and ultraviolet ray ageing-resisting. The unique configuration of floats has great buoyancy reserve, and high intensity and stability. Universal connectors make quick and reliable connection impossible. The surface of the boom is convenient to guide spilt oil and to be cleaned.
Customers can choose tensile ballast chains or ballast blocks for different needs. There is an optional advanced luminous marker on the boom for indicating the position of the boom in the night. Customers can also select special rubber booms with anti-fire properties. All necessary auxiliaries for booms can be selected or specially designed according to users' requirements, and our company can supply customers with technical materials and special support
TECHNICAL DATA OF float rubber boom
Item |
JFW600 |
JFW800 |
GFW1000 |
GFW1200 |
GFW1400 |
GFW1600 |
HFW1800 |
HFW2000 |
Overall Height (mm) |
600 |
800 |
1000 |
1200 |
1400 |
1600 |
1800 |
2000 |
Freeboard (mm) |
210 |
280 |
340 |
400 |
460 |
520 |
590 |
660 |
Draft (mm) |
280 |
360 |
480 |
600 |
700 |
810 |
900 |
1000 |
Standard Section Length (m) |
20,15,10 |
|||||||
Float Diameter (mm) |
200 |
280 |
315 |
360 |
420 |
480 |
540 |
600 |
Float Numbers /20m |
22 |
14 |
12 |
12 |
12 |
12 |
12 |
12 |
Weight (kg/m) |
5.0 |
6.8 |
9.2 |
12 |
13 |
14 |
15 |
16 |
Buoyancy to Weight Ratio |
3.4 |
5.8 |
5.7 |
5.5 |
6.9 |
8.3 |
9.8 |
11.3 |
Ballast Chain (mm) |
10 |
10 |
14 |
16 |
16 |
18 |
18 |
18 |
Max. Tensile Strength Across boom Wall (KN) |
240 |
320 |
400 |
480 |
560 |
640 |
720 |
800 |
Operation Load (KN) |
100 |
100 |
220 |
300 |
300 |
380 |
380 |
380 |
Operation Temp Range () |
-30~+60 |
|||||||
Store Temp Range () |
-30~+70 |
|||||||
Efficient in Wave up to (m) |
1.5 |
2 |
2 |
2.5 |
3 |
3 |
3.5 |
3.5 |
Survival Condition (m/s) |
10 |
15 |
15 |
20 |
20 |
20 |
25 |
25 |
Stable in Current up to (Kn) |
1.5 |
2 |
2.5 |
3 |
3 |
3 |
3 |
3-4 |
Max. Speed of Line Towing (Kn) |
8 |
|||||||
Max. Speed of Arc towing (Kn) |
3 |
|||||||
Type of Connection |
gemel style, hook style |
|||||||
