nonwoven spunbond

Specifications

Applicate for spunbond nonwoven cloth forming with different air permeability



Product picture







Technical data





Name	BGW22608
Material&Diameter	Warp:polyester flat monofilament          yarn(0.38mmx0.58mm)
	Weft:polyester flat monofilament            yarn(0.60mm)
Weight(g/m2)	1150
Thickness(mm)	1.71
Density(counts/cm)	Warp:22
	Weft:10.2
Tensile strength(N/5X20cm)	Warp:8378
	Weft:7554
Elogation(%)	Warp:32.33
	Weft:51.3
Air permeability(m3/m2.h@200pa)	9865









Name	BGW20604
Material&Diameter	Warp:polyester flat monofilament          yarn(0.38mmx0.58mm)
	Weft:polyester flat monofilament            yarn(0.60mm)
Weight(g/m2)	760
Thickness(mm)	1.33
Density(counts/cm)	Warp:20.4
	Weft:7
Tensile strength(N/5X20cm)	Warp:5889
	Weft:4815
Elogation(%)	22.6
	34.2
Air permeability(m3/m2.h@200pa)	11628



Name	GW22508
Material&Diameter	Warp:polyester monofilament          yarn(0.50mm)
	Weft:polyester monofilament            yarn(0.50mm)
Weight(g/m2)	870
Thickness(mm)	1.8
Density(counts/cm)	Warp:22
	Weft:10
Tensile strength(N/5X20cm)	Warp:5965
	Weft:5215
Elogation(%)	21.9
	32.2
Air permeability(m3/m2.h@200pa)	12985



Where to use?



Applicable for S SS and SMS types spunbond nonwoven forming.





We have following types of spunbond belt, include

BGW20604;BGW22608 and GW22508.

our customer can select different types according to their different requirement about the air permeability.

GW22508 mainly use for low speed S spunbond nonwoven machine.

BGW20604 and BGW22608 mainly use for high speed SS and SMS spunbond meltbrown machine.



Advantage



1.The reusable bags widely used is made by spunbond nonwoven cloth, our spunbond belt BGW20604; BGW22608 and GW22508 is use for spunbond nonwoven forming. it design for customer's different requirement about air permeability.



2.The raw material of spunbond nonwoven cloth is PE or PP, it will cause static during production, so we'll do anti-static treatment for our spunbond belt. we'll use anti-static wires for our belt, or do anti-static dipping for our belt. so our spunbond belt is best for our customer's selection.



3.We make self pin joint for our spunbond belt, it's easy to install, not left any seam marks in the nonwoven cloth. the intensity can reach 100% of the fabrics.



Processing



Warping--Buckling--Weaving--Once heat set--Twice heat set--Edge reinforcement--Packing--Finish











Treatment



We make self pin joint and resin edge reinforcement for our spunbond belt.









Inspection



We use air permeability test apparatus for air permeability testing, and breaking force test apparatus is use for tensile strength testing.









Packing



We have three types of packing, poly bag; wooden box and carton, our customers can select either one according to their request.







Do you need a price? if yes,please tell us these information as below:

 1.Your detailed technical requirement.

 2.Your usage or application of our products.

 3.Your width and length,detailed measurement.

 4.Terms of shipment.

 5.The packing you need for shipping.

 6.Which joint you want.

 7.Do you need any treatment.

 Any questions, pls feel free to contact with us.
