PP Spunbond Nonwoven Fabric

PP Spunbond Nonwoven Fabric thumbnail-1
PP Spunbond Nonwoven Fabric photo-1
US$ 15 - 50 MOQ: 100 Square Meters
Key Specifications
Get Latest Price
Supply Type:
Make-to-Order
Material:
100% Polyester
Nonwoven Technics:
Spun-Bonded
Contact Supplier Request Quote Chat Now
Zhejiang Huading Net Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Supply Type Make-to-Order
Material 100% Polyester
Nonwoven Technics Spun-Bonded
Pattern Dyed
Style Plain
Width Other, 43/44"
Feature Anti-Static
Use Hospital, Agriculture, Bag, Industry
Weight ISO9001:2008
Place of Origin Zhejiang, China
Brand Name HUADING
Model Number BGW22608/BGW20604/GW22508

Specifications

Applicate for spunbond nonwoven cloth forming with different air permeability

PP spunbond nonwoven fabric

PP spunbond nonwoven fabric

PP spunbond nonwoven fabric



Product picture



PP spunbond nonwoven fabric

 PP spunbond nonwoven fabric

PP spunbond nonwoven fabric



Technical data





Name BGW22608
Material&Diameter

Warp:polyester flat monofilament

         yarn(0.38mmx0.58mm)

Weft:polyester flat monofilament

        yarn(0.60mm)

Weight(g/m2) 1150
Thickness(mm) 1.71
Density(counts/cm) Warp:22
Weft:10.2
Tensile strength(N/5X20cm)  Warp:8378
Weft:7554
Elogation(%)  Warp:32.33
Weft:51.3
Air permeability(m3/m2.h@200pa) 9865









Name BGW20604
Material&Diameter

Warp:polyester flat monofilament

         yarn(0.38mmx0.58mm)

Weft:polyester flat monofilament

        yarn(0.60mm)

Weight(g/m2) 760
Thickness(mm) 1.33
Density(counts/cm) Warp:20.4
Weft:7
Tensile strength(N/5X20cm)  Warp:5889
Weft:4815
Elogation(%)   22.6
 34.2
Air permeability(m3/m2.h@200pa)  11628



Name GW22508
Material&Diameter

Warp:polyester monofilament

         yarn(0.50mm)

Weft:polyester monofilament

        yarn(0.50mm)

Weight(g/m2) 870
Thickness(mm) 1.8
Density(counts/cm) Warp:22
Weft:10
Tensile strength(N/5X20cm)  Warp:5965
Weft:5215
Elogation(%)   21.9
 32.2
Air permeability(m3/m2.h@200pa)  12985



Where to use?



Applicable for S SS and SMS types spunbond nonwoven forming.



 PP spunbond nonwoven fabric

We have following types of spunbond belt, include

BGW20604;BGW22608 and GW22508.

our customer can select different types according to their different requirement about the air permeability.

GW22508 mainly use for low speed S spunbond nonwoven machine.

BGW20604 and BGW22608 mainly use for high speed SS and SMS spunbond meltbrown machine.



Advantage



1.The reusable bags widely used is made by spunbond nonwoven cloth, our spunbond belt BGW20604; BGW22608 and GW22508 is use for spunbond nonwoven forming. it design for customer's different requirement about air permeability.



2.The raw material of spunbond nonwoven cloth is PE or PP, it will cause static during production, so we'll do anti-static treatment for our spunbond belt. we'll use anti-static wires for our belt, or do anti-static dipping for our belt. so our spunbond belt is best for our customer's selection.



3.We make self pin joint for our spunbond belt, it's easy to install, not left any seam marks in the nonwoven cloth. the intensity can reach 100% of the fabrics.



Processing



Warping--Buckling--Weaving--Once heat set--Twice heat set--Edge reinforcement--Packing--Finish



 PP spunbond nonwoven fabric







Treatment



We make self pin joint and resin edge reinforcement for our spunbond belt.



 PP spunbond nonwoven fabric

 PP spunbond nonwoven fabric



Inspection



We use air permeability test apparatus for air permeability testing, and breaking force test apparatus is use for tensile strength testing.



 PP spunbond nonwoven fabric

 PP spunbond nonwoven fabric



Packing



We have three types of packing, poly bag; wooden box and carton, our customers can select either one according to their request.



PP spunbond nonwoven fabric



Do you need a price? if yes,please tell us these information as below:

 1.Your detailed technical requirement.

 2.Your usage or application of our products.

 3.Your width and length,detailed measurement.

 4.Terms of shipment.

 5.The packing you need for shipping.

 6.Which joint you want.

 7.Do you need any treatment.

 Any questions, pls feel free to contact with us.

 PP spunbond nonwoven fabric
