Pet Wide Neck Jar Stretch Blow Molding Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Deshuo
Model Number:
YK1500-2GK
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hand Feed Preform Blow Molding MachineNegotiableMOQ: 1 -
2 Stage Pet Servo 4 Cavity Blow Molding MachineNegotiableMOQ: 1 Unit
-
Manual Hand Preform Blow Molding MachineNegotiableMOQ: 1
-
Automatic Pet Stretch Blow Molding MachineNegotiableMOQ: 1
-
Automatic PET Stretch Blow Molding MachineNegotiableMOQ: 1 Set
Condition
New
Brand Name
Deshuo
Model Number
YK1500-2GK
Place of Origin
Zhejiang, China
Plastic Type
Thermoplastic
After-sales Service Provided
Engineers available to service machinery overseas
automatic PET Jar Stretch Blow Moulding Machine
DETAILS OF this MACHINE
2cavity /1.5L / Wide NECK Jar
We endeavor to be the stable performance full-automatic pet bottle Beverage blow molding Packaging machinery supplier for our friends
- Optimization design of a integrated templates,high strength,using lifetime
- Template precision machining,running rapid and stable.
- Can add high pressure gas recovery device as low pressure use.
- Frequency conversion temperature and layered heationg system make heating euality,finishined product stable.
- auto-fault detection.
- use the advanced touch-screen computer control,easy operation.
- Automatic feeding preform and picking up finished bottles.
- Modular design.
Beacause we have many kinds of machines to blow diferent volume pet bottle
if you have any doubt in choosing machine,you can write to me directly or call me toask for detailed model of each machine.I will to reply you asap to help you.
| Automatic Pet Wide-neck Machine--YK1500-2GK | |||||
| Specification | Item | Date | |||
| Blow Moulding Machine |
Model | YK1500-2GK | |||
| Container Volume | 1.5L | ||||
| No.of Cavity | 2 | ||||
| Mould Stroke | 125mm | ||||
| Mould Thickness | 180mm | ||||
| Total Power | 50kw | ||||
| Use Power | 10-15kw | ||||
| Theoretical Output | 2000bph(*) | ||||
| Container | Max.Bottle Diameter | 93mm | |||
| Max.Bottle Height | 340mm | ||||
| Max.Screw Size | 93mm | ||||
| Air Compressor | Working Pressure | 10bar | |||
| Air Consuming | 1.6 | ||||
| Blowing Pressure | 30bar | ||||
| Air Consuming | 2 | ||||
| Water Cooling | Operation pressure |
5-10bar | |||
| Temperature Range | 10℃ | ||||
| Water Consuming | 30L/min | ||||
| Machine Size | Size | 3.1*1.5*2 M | |||
| Weight | 2000kg | ||||
| Feeding System Size |
Size | 0.4*2*1.3 M | |||
| Weight | 80kg |
||||
