Gen2 passive rfid reader uhf handheld with bluetooth 4.0 /usb 2.0
Introduction
l Based on independent intellectual property development, adapt reader to work with global frequency range;
l High performance with Bluetooth easily communicate with smart terminal (smart phone, tablet PC).
Features
1. Save repeat purchase cost by operation online with available PDA, smart phone and tablet PC via Bluetooth communication;
2. Support reading/writing electronic tags up to ISO-18000-6B,ISO-18000-6C(EPC G2);
3. Easy to read tags and meanwhile easy to check/confirm on PDA screen;
4. Low cost, more economical than handheld reader integrating with PDA;
5. Reliable industrial structure design, workable in varied severe environment.
Specification
|
|
Model# |
VH-75 |
Performance Index | |
Frequency Range |
865-868MHZ,902-928MHZ(or customized) |
FM mode |
FHSS or fixed frequency, set by the software |
RF output power |
30 dBm adjustable |
Communication interface |
USB1.1, Bluetooth IEEE802.15 ( rate 1Mbps) |
Tag Operation Performance | |
Reading distance |
Read >200cm, Write >20cm |
Air interface |
ISO-18000-6B,ISO-18000-6C(EPC G2) |
Mechanical and Electrical Performance | |
Dimension |
180(L)*55 (W)*30(H)mm |
Power supply |
Rechargeable Li-ion polymer battery (3.7V,3200mAH) |
Reading instructions |
Vibration motor,Buzzer,LED |
Memory Card |
2G(MiniSD) |
Standby time |
150 hours, scan times for once charging: 5000 |
Weight |
250g |
Humidity |
5% to 95%, non-condensed |
Protection grade |
IEC IP56 |
Operation temperature |
-20 ºC to +50 ºC |
Storage temperature |
-25°C to70°C |
