Garment Retail Uhf Rfid Sense Gate Reader for Loss Detection

Name: Garment Retail Uhf Rfid Sense Gate Reader for Loss Detection
Brand: VANCH
SKU: 101693697
Availability: InStock

US$ 1,580 - 1,650 MOQ: 1 Pair

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

VANCH

Model Number:

VC-420T

Shenzhen Vanch Intelligent Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name VANCH

Model Number VC-420T

garment retail uhf rfid sense gate reader for loss detection

Product Description

Introduction:

l Based on independent intellectual property development, adapt reader to work with global frequency range.

l RFID gate reader is combined by RFID antennas, reader, EAS sound and light alarm system, power supply and

l other assistant equipments. When goods or person attached with RFID tag go through the channel, RFID antenna

l will read the information and real time send to reader and related processor, to achieve the goods or person

l management.

l Application: warehouse assets management, meeting attendance, clothes industry, books and files industry,

l manufacturing control and other open fields with big flows.

Features:

1. Support tags conforming to standards EPC global UHF ISO-18000-6C (EPC G2), TK900;
2. Frequency range 902~928MHZ(or customized);
3. Support multi communication interfaces (LAN, RS232, RS485, Wiegand26/34);
4. 4 SMA antenna ports, 7dbi circular polarization antenna, the height of antenna adjustable;
5. RF output power 20 ~30dBm adjustable, support auto, command, trigger work modes;
6. Reliable industry structure design, workable in varied severe environment.

Specification

Model#	VC-420T
Performance Index
Frequency range	902-928MHZ(or customized)
FM mode	FHSS or fixed frequency, set by the software
RF output	20-30dBm adjustable
Antenna connection qty’	4 SMA antenna ports, 7dbi circular polarization antenna, the height of antenna adjustable
Communication interface	LAN,RS232,RS485,Wiegand26/34
Communication rate	Serial port 9600~115200bps,RJ45 10Mbps
Power dissipation	average<20W
EAS alarm	3s sound and light prompt
GP I/O interface	12 pin + 4 pin
Reliable firmware upgrade	Extensible upgrade mechanism
Application software interface	Provide with API SDK and VC, VB, Java application routines
Tag Operation Performance
Reading distance	1.5-3m equipped with 7dbi antenna (tag dependent)
Air interface	EPC global UHF ISO-18000-6C(EPC G2),TK900
Mechanical and Electrical Performance
Dimension	157(L)x44.5 (W)x13(H)cm
Power supply	220V AC input
Weight	20KG
Humidity	5% to 95%, non-condensing
Protection grade	IEC IP51
Operation temperature	-20 ºC to +60 ºC
Storage temperature	-40°C to 80°C
