RSSI UHF RFID Android System Handheld Reader

Name: RSSI UHF RFID Android System Handheld Reader
Brand: VANCH
SKU: 101693747
Availability: InStock

Shenzhen Vanch Intelligent Technology Co., Ltd.

US$ 1,200 - 1,280 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

VANCH

Model Number:

VH-770AT

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name VANCH

Model Number VH-770AT

RSSI UHF RFID android system handheld reader

Introduction

l Based on independent intellectual property development, adapt reader to work with global frequency range.

l Application: warehousing and logistics management, assets inventory, production automation management and other data acquisition system.

Features

1. Support kinds of different modules optional, adapt to users’ different requirement;

2. Support EPC Class1 Gen2 / ISO18000-6C;

3. Output power can be adjustable by software,10~28dBm,1dBm step by step;

4. Read distance up to 7 meters(96mm*15mm tag);

5. Integration with Wifi 802.11b/g;

6. Ergonomics design handle, easy to handhold, relieve user’s feeling of fatigue to operate;

7. Continuous working time up to 4 hours, standby time about 20 days;

8. Industrial structure with high reliable design, meets harsh work environment requir

Specification

performance & physical parameter
Protocol	EPC Class1 Gen2/ISO18000-6C
CPU	High speed ARM platform,main frequency 450MHZ
OS	Android system 4.2
RAM	2G
Memory card	2G Micro SD(standard configuration),support 32G at max.
Barcode module options
1D module	Symbol SE955
2D module	Honeywell 5180 (optional)
WIFI	WLAN 802.11 b/g (standard configuration)
Extend module	4G
Communication interface	USB Slave
Audio	Typhoon, support multi-media function
Dimension	183mm* 81mm*146mm
Weight	703g(excluding charging base)
Key	27 keys
Display & physical parameter
Screen	5.0 inch TFT LCD(240*320),resistive touch screen, backlight adjustable
Battery	Rechargeable lithium polymer battery(3500mAh @ 7.4V )
Operation temperature	-20° C~+50° C
Storage temperature	-30° C~+70° C
Humidity	5%~95% non-condensing(25°C)
Accessories	9V/1A charging base,USB cable
Frequency parameter
US	902 ~928MHz
CN	920 ~ 925MHz
EU	865 ~ 868MHz,other standard can be customized
Read distance	7 meters at max.(tag dependent)
Write distance	3 meters at max.(tag dependent)
