long range rfid reader access control system
Specification |
|
Model# |
VI-88C |
Performance Index | |
Frequency range |
902-928MHZ(or customized) |
FM mode |
FHSS or fixed frequency, set by the software |
RF output |
30dBm adjustable |
Communication interface |
LAN,RS232,RS485,Wiegand26/34 |
Communication rate |
Serial port 9600~115200bps,RJ45 10Mbps |
I/O interface |
TTL |
Power dissipation |
average<15W |
Application software |
Provide with API SDK and VC, VB, Java application routines |
Tag Operation Performance | |
Reading distance |
5~18m equipped with 12dbi antenna(tag dependent) |
Air interface |
EPC global UHF ISO-18000-6C(EPC G2),ISO-18000-6B |
Mechanical and Electrical Performance | |
Dimension |
445(L)*445 (W)*70(H)mm |
Power supply |
Equipped with power convertor 220V AC input, +9V/3A DC output |
Weight |
2KG |
Humidity |
5% to 95%, non-condensing |
Protection grade |
IEC IP54 |
Operation temperature |
-20 ºC to +60 ºC |
Storage temperature |
-40°C to 80°C |
Shenzhen VANCH Intelligent Technology Co., Ltd.
1. You are manufacturer or trading company?
We are original equipment manufacturer in RFID UHF reader for over 10 years.
2. How is your QC?
We have strict QC process and all the products will be 100% testing before shipping.
3. What is your payment term?
100% payment should be paid before shipping.
4. What is your payment way?
T/T, Western Union, MoneyGram
5. What is your warranty?
Wthin 1 year.
6. Can I get technical support from you?
Sure. Our sales are of all good knowledge in the field. Besides, we have a technical team behind to support.
