Specification

Model#

VI-88C

Performance Index

Frequency range

902-928MHZ(or customized)

FM mode

FHSS or fixed frequency, set by the software

RF output

30dBm adjustable

Communication interface

LAN,RS232,RS485,Wiegand26/34

Communication rate

Serial port 9600~115200bps,RJ45 10Mbps

I/O interface

TTL

Power dissipation

average<15W

Application software

Provide with API SDK and VC, VB, Java application routines

Tag Operation Performance

Reading distance

5~18m equipped with 12dbi antenna(tag dependent)

Air interface

EPC global UHF ISO-18000-6C(EPC G2),ISO-18000-6B

Mechanical and Electrical Performance

Dimension

445(L)*445 (W)*70(H)mm

Power supply

Equipped with power convertor 220V AC input, +9V/3A DC output

Weight

2KG

Humidity

5% to 95%, non-condensing

Protection grade

IEC IP54

Operation temperature

-20 ºC to +60  ºC

Storage temperature

-40°C to 80°C
