8M Long Range UHF RFID LED Reader,902~928mhz Frequency Band Support ISO18000-6C(EPC C1G2) Protocol



Introduction:Application: logistics, access control, parking management, manufacturing control and etc

Freatures:Reliable industry structure design, workable in varied severe environment.

Model#

VI-89F

Performance Index

Frequency range

902-928MHZ(or customized)

FM mode

FHSS or fixed frequency, set by the software

RF output

30dBm adjustable;50Ω load

Communication interface

RS232,RS485,Wiegand26/34(TCP/IP)

Communication rate

Serial port 9600~115200bps,RJ45 10Mbps

GP I/O interface

12 pin + 4 pin

Power dissipation

average<10W

Application software

Provide with API SDK and VC, VB, Java application routines

Tag Operation Performance

Reading distance

6~10m equipped with 9dbi antenna(tag dependent)

Air interface

EPC global UHF ISO-18000-6C(EPC G2), ISO-18000-6B

Mechanical and Electrical Performance

Dimension

306(L)*306(W)*25(H)mm(excluding mounting bracket and external wiring)

Power supply

Equipped with power convertor 220V AC input, +9V/3A DC output

Weight

2.6Kg

Installation

Embrace rod mounting

Diameter of support rod

40-50mm

Humidity

5% to 95%, non-condensing

Protection grade

IEC IP65

Operation temperature

-20 ºC to +60  ºC



8M Long Range UHF RFID LED Reader,902~928mhz Frequency Band Support ISO18000-6C(EPC C1G2) Protocol 8M Long Range UHF RFID LED Reader,902~928mhz Frequency Band Support ISO18000-6C(EPC C1G2) Protocol8M Long Range UHF RFID LED Reader,902~928mhz Frequency Band Support ISO18000-6C(EPC C1G2) Protocol

8M Long Range UHF RFID LED Reader,902~928mhz Frequency Band Support ISO18000-6C(EPC C1G2) Protocol8M Long Range UHF RFID LED Reader,902~928mhz Frequency Band Support ISO18000-6C(EPC C1G2) Protocol8M Long Range UHF RFID LED Reader,902~928mhz Frequency Band Support ISO18000-6C(EPC C1G2) Protocol8M Long Range UHF RFID LED Reader,902~928mhz Frequency Band Support ISO18000-6C(EPC C1G2) Protocol

FAQ





Q: You are factory or trading company?

A:  We are original equipment manufacturer in RFID UHF reader for over 10 years.



Q: How is your QC?

A: We have strict QC process and all the products will be 100% testing before shipping.



Q: What is your payment term?

A: 100% payment should be paid before shipping.



Q: What is your payment way?

A: T/T, Western Union, MoneyGram



Q: What is your warranty?

A: within 1 year.



Q: Can I get technical support from you?

A:  Sure. Our sales are of all good knowledge in the field. Besides, we have a technical team behind to support.
