XCMG XE700C Crawler Excavator

Name: XCMG XE700C Crawler Excavator
Brand: XCMG
SKU: 101672269
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

XCMG

Model Number:

XE700C

Condition:

New

Jiangsu Sinma Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Brand Name XCMG

Model Number XE700C

Condition New

Moving Type Crawler Excavator

Operating Weight 68000kg

Bucket capacity 3.1-3.5m³

Maximum Digging Height 11350mm

Maximum Digging Depth 6900

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

XCMG excavator is widely used in construction sites,mining,road construction and etc.

Model		Unit	XE700C
Operating weight		kg	68000
Standard bucket capacity		m³	3.1~3.5
Engine	Engine Model	/	Cummins QSX15
	Direct injection	/	√
	Four strokes	/	√
	Water cooling	/	√
	Turbo charged	/	√
	Air to air intercooler	/	√
	No. of cylinders	/	6
	Rated power/speed	kw/rpm	336/1800
	Max. torque/speed	N.m	2102/1400
	Displacement	L	15
The main performance	Travel speed	km/h	4.2/3.0
	Swing speed	r/min	7
	Max. gradeability	/	≥30
	Ground pressure	kPa	99.1
	Max.Bucket digging force	kN	370
	Max.arm crowd force	kN	354
	Max.traction force	kN	450
Hydraulic system	Main pump	/	2 Plunger pump
	Rate flow of main pump	L/min	2×450
	Max pressure of prime relief valve	MPa	31.4/34.3
	Max pressure of travel system	MPa	34.3
	Max pressure of swing system	MPa	25.5
	Max pressure of pilot system	MPa	3.9
Oil capacity	Fuel tank capacity	L	980
	Hydraulic tank capacity	L	455
	Engine lubrication	L	48
Overall dimensions	A Overall length	mm	11940
	B Overall width	mm	4280
	C Overall height	mm	4700
	D Overall width of upperstructure	mm	3260
	E Track length	mm	5955
	F Overall width of undercarriage	mm	4260
	G Crawer width	mm	650
	H Track length on ground	mm	4680
	I Crawer gauge	mm	2800/3350
	J Clearance under counter weight	mm	1552
	K Ground clearance	mm	853
	L Min.tail swing radius	mm	3900
Working range	A Max. digging height	mm	11350
	B Max. dumping height	mm	7370
	C Max. digging depth	mm	6900
	D 8inch horizonal digging depth	mm	6750
	E Max. vertical wall digging depth	mm	5500
	F Max. digging reach	mm	11580
	G Min. swing radius	mm	4750
	Angle of arm deflection	Degree
