Huawei AP6010 Series Indoor Wireless Access Point Wifi 5.8ghz Access Point

Name: Huawei AP6010 Series Indoor Wireless Access Point Wifi 5.8ghz Access Point
Brand: Huawei
SKU: 101661265
Availability: InStock

Huawei AP6010 Series Indoor Wireless Access Point Wifi 5.8ghz Access Point thumbnail-1

Huawei AP6010 Series Indoor Wireless Access Point Wifi 5.8ghz Access Point photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

Huawei

Model Number:

AP6010

Contact Supplier Request Quote Chat Now

Shanghai Chu Cheng Information Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name Huawei

Model Number AP6010

Huawei AP6010 Series Access Point

The AP6010 series enhanced access points use an elegant design and are intended for use in medium- and large-scale deployment scenarios, such as educational institutions, enterprise offices, airports, stations, and retail markets . This series is available in two models: AP6010SN-GN and AP6010DN-AGN.
• 2×2MIMO (two spatial streams)
• Fit/Fat mode
• PoE or DC power supply
• Built-in antennas
• 20 dbm

Specifications

Item		Description
Technical specifications	Dimensions (H×W×D)	50 mm×180 mm×180 mm
	Weight	0.4 kg
	System memory	128 MB DRAM 32 MB flash memory
Power specifications	Power input	DC 12V±10% POE Power: -48V DC PoE function in compliance with IEEE 802.3af and 802.3at
Power specifications	Maximum power consumption	AP6010DN-AGN: 10.2 W AP6010SN-GN: 6.5 W NOTE:The maximum power consumption depends on local laws.
Environment parameters	Operating temperature	-10°C to +50°C
	Storage temperature	-40°C to +70°C
	Humidity	5% to 95% (non-condensing)
	Waterproof grade	IP31
	Altitude	-60m to 4000 m

Radio Specifications

Item	Description
Antenna type	Built-in antenna
Antenna gain	AP6010DN-AGN 2.4 GHz: 4 dBi 5 GHz: 5 dBi AP6010SN-GN: 4 dBi
Maximum number of concurrent users	128
Maximum transmit power	20dBm You can adjust the transmit power from the maximum transmit power by 20 dB, with a step of 1 dB. NOTE:Actual transmit power depends on local laws and regulations.
Maximum number of non-overlapping channels for AP6010DN-AGN	2.4 GHz 802.11b/g 20MHz: 3 802.11n 20MHz: 3 40MHz: 1					5 GHz 802.11a 20MHz: 24 802.11n 20MHz: 24 40MHz: 11
Maximum number of non-overlapping channels for AP6010DN-AGN	NOTE:The number of non-overlapping channels allowed varies in different countries. For details, see the Country codes & Channels compliance status
Maximum number of non-overlapping channels for AP6010SN-GN	802.11b/g 20MHz: 3 802.11n 20MHz: 3 40MHz: 1
Maximum number of non-overlapping channels for AP6010SN-GN	NOTE:The number of non-overlapping channels allowed varies in different countries. For details, see the Country codes & Channels compliance status
Channel Rate	802.11b: 1, 2, 5.5, and 11 Mbit/s
	802.11g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/s
	802.11n data rate: AP6010DN-AGN: 2.4 GHz and 5 GHz AP6010SN-GN: 2.4 GHz
	GI2=800ns				GI=400ns
	20 MHz (Mbit/s)		40 MHz (Mbit/s)		20 MHz (Mbit/s)			40 MHz (Mbit/s)
	6.5 @ MCS10		13.5 @ MCS0		7.2 @ MCS0			15 @ MCS0
	13 @ MCS1		27 @ MCS1		14.4 @ MCS1			30 @ MCS1
	19.5 @ MCS2		40.5 @ MCS2		21.7 @ MCS2			45 @ MCS2
	26 @ MCS3		54 @ MCS3		28.9 @ MCS3			60 @ MCS3
	39 @ MCS4		81 @ MCS4		43.3 @ MCS4			90 @ MCS4
	52 @ MCS5		108 @ MCS5		57.8 @ MCS5			120 @ MCS5
	58.5 @ MCS6		121.5 @ MCS6		65 @ MCS6			135 @ MCS6
	65 @ MCS7		135 @ MCS7		72.2 @ MCS7			150 @ MCS7
	13 @ MCS8		27 @ MCS8		14.4 @ MCS8			30 @ MCS8
	26 @ MCS9		54 @ MCS9		28.9 @ MCS9			60 @ MCS9
	39 @ MCS10		81 @ MCS10		43.3 @ MCS10			90 @ MCS10
	52 @ MCS11		108 @ MCS11		57.8 @ MCS11			120 @ MCS11
	78 @ MCS12		162 @ MCS12		86.7 @ MCS12			180 @ MCS12
	104 @ MCS13		216 @ MCS13		115.6 @ MCS13			240 @ MCS13
	117 @ MCS14		243 @ MCS14		130 @ MCS14			270 @ MCS14
	130 @ MCS15		270 @ MCS15		144.4 @ MCS15			300 @ MCS15
	NOTE:Modulation coding scheme (MCS) index: determines the spatial flow quantity, modulation, coding rate, and data rate. Guard interval (GI): indicates the period in nanoseconds the radio listens between packets.
Receiver sensitivity of the AP6010DN-AGN	2.4 GHz 802.11b (CCK) -97 dBm @ 1 Mbit/s -92 dBm @ 2 Mbit/s -92 dBm @ 5.5 Mbit/s -90 dBm @ 11 Mbit/s	2.4 GHz 802.11g (non-HT20) -92 dBm @ 6 Mbit/s -91 dBm @ 9 Mbit/s -90 dBm @ 12 Mbit/s -87 dBm @ 18 Mbit/s -83 dBm @ 24 Mbit/s -80 dBm @ 36 Mbit/s -76 dBm @ 48 Mbit/s -74 dBm @ 54 Mbit/s		2.4 GHz 802.11n (HT20) -92 dBm @ MCS0/8 -89 dBm @ MCS1/9 -86 dBm @ MCS2/10 -82 dBm @ MCS3/11 -79 dBm @ MCS4/12 -74 dBm @ MCS5/13 -73 dBm @ MCS6/14 -71 dBm @ MCS7/15			2.4 GHz 802.11n (HT40) -89 dBm @ MCS0/8 -86 dBm @ MCS1/9 -83 dBm @ MCS2/10 -79 dBm @ MCS3/11 -76 dBm @ MCS4/12 -72 dBm @ MCS5/13 -70 dBm @ MCS6/14 -68 dBm @ MCS7/15
Receiver sensitivity of the AP6010DN-AGN	5 GHz 802.11a (non-HT20) -89 dBm @ 6 Mbit/s -88 dBm @ 9 Mbit/s -85 dBm @ 12 Mbit/s -83 dBm @ 18 Mbit/s -80 dBm @ 24 Mbit/s -76 dBm @ 36 Mbit/s -71 dBm @ 48 Mbit/s -70 dBm @ 54 Mbit/s	5 GHz 802.11n (HT20) -88 dBm @ MCS0/8 -85 dBm @ MCS1/9 -84 dBm @ MCS2/10 -77 dBm @ MCS3/11 -74 dBm @ MCS4/12 -70 dBm @ MCS5/13 -68 dBm @ MCS6/14 -67 dBm @ MCS7/15		5 GHz 802.11n (HT40) -85 dBm @ MCS0/8 -80 dBm @ MCS1/9 -78 dBm @ MCS2/10 -74 dBm @ MCS3/11 -71 dBm @ MCS4/12 -67 dBm @ MCS5/13 -65 dBm @ MCS6/14 -63 dBm @ MCS7/15
Receiver sensitivity of the AP6010SN-GN	802.11b (CCK): -97 dBm @ 1 Mbit/s -92 dBm @ 2 Mbit/s -92 dBm @ 5.5 Mbit/s -90 dBm @ 11 Mbit/s	802.11g (non-HT20): -92 dBm @ 6 Mbit/s -91 dBm @ 9 Mbit/s -90 dBm @ 12 Mbit/s -87 dBm @ 18 Mbit/s -83 dBm @ 24 Mbit/s -80 dBm @ 36 Mbit/s -76 dBm @ 48 Mbit/s -74 dBm @ 54 Mbit/s		802.11n (HT20): -92 dBm @ MCS0/8 -89 dBm @ MCS1/9 -86 dBm @ MCS2/10 -82 dBm @ MCS3/11 -79 dBm @ MCS4/12 -74 dBm @ MCS5/13 -73 dBm @ MCS6/14 -71 dBm @ MCS7/15			802.11n (HT40): -89 dBm @ MCS0/8 -86 dBm @ MCS1/9 -83 dBm @ MCS2/10 -79 dBm @ MCS3/11 -76 dBm @ MCS4/12 -72 dBm @ MCS5/13 -70 dBm @ MCS6/14 -68 dBm @ MCS7/15

WLAN features

AP6010DN-AGN: complies with IEEE 802.11a/b/g/n.
AP6010SN-GN: complies with IEEE 802.11b/g/n.
AP6010DN-AGN, and AP6010SN-GN: provides a maximum rate of 300 Mbit/s.
Maximum ratio combining (MRC)
Maximum-likelihood detection (MLD)
Data unit aggregation, including A-MPDU (Tx/Rx) and A-MSDU (Rx only)
AP6010DN-AGN: supports 802.11 dynamic frequency selection (DFS).
Short GI in 20 MHz and 40 MHz modes
Priority mapping and packet scheduling based on a Wi-Fi Multimedia (WMM) profile to implement priority-based data processing and forwarding
Automatic and manual rate adjustment (the rate is adjusted automatically by default)
WLAN channel management and channel rate adjustment
Automatic channel scanning and interference avoidance
Service set identifier (SSID) hiding
Signal sustain technology (SST)
Unscheduled automatic power save delivery (U-APSD)
Control and Provisioning of Wireless Access Points (CAPWAP) in Fit AP mode
Automatic login in Fit AP mode
Wireless distribution system (WDS) in Fit AP mode
Mesh networking in Fit AP mode

Deployment

The AP6010DN-AGN and AP6010SN-GN provide wireless services for enterprise scenarios with medium size, dense users, and high capacity demands. The AP6010DN-AGN can be flexibly deployed and work in both fit AP and bridge mode.

The AP6010DN-AGN and AP6010SN-GN can work as a Fat AP or Fit AP and switch flexibly between the two working modes based on the network plan.

When the wireless network scale is small, customers need to purchase only AP products and set the APs to work as Fat APs. As the network scale expands, tens of or hundreds of APs exist on the network. To simplify network management, customers are advised to purchase ACs to perform centralized management on the APs and set the APs to work as Fit APs.
