Huawei AP7110 Series Indoor Wireless Access Point Long Range Wireless Access Point
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Huawei
Model Number:
AP7110
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Huawei AP7110 Series Indoor Wireless Access Point in Wall Access PointNegotiableMOQ: 1 Piece -
Huawei AP7110 Series Indoor Wireless Access Point Wall Mount Access PointNegotiableMOQ: 1 Piece
-
Huawei AP6010 Series Indoor Wireless Access PointNegotiableMOQ: 1 Piece
-
Huawei AP6010 Series Indoor Wireless Access Point Mini Usb Wireless Access PointNegotiableMOQ: 1 Piece
-
Huawei AP6010 Series Indoor Wireless Access Point Wifi Mini Access PointNegotiableMOQ: 1 Piece
Place of Origin
Shanghai, China
Brand Name
Huawei
Model Number
AP7110
Huawei AP7110 Series Access Point
The AP7110 series premium access points provide highly reliable and secure wireless services and radio frequencies for high-density or large scenarios, such as exhibition centers, medical organizations, factories, and logistics networks. This series is available in two models: AP7110SN-GN and AP7110DN-AGN.
• 3×3MIMO (three spatial streams)
• PoE or DC power supply
• External antennas
• 20 dbm
Specifications
| Item | Description | |
|---|---|---|
| Technical specifications | Dimensions (H×W×D) | 45 mm×200 mm×200 mm |
| Weight | 1.0 kg | |
| System memory | 256 MB DDR3 32 MB flash memory |
|
| Power specifications | Power input | DC 12V±10% POE Power: -48V DC AP7110SN-GN: PoE function in compliance with IEEE 802.3af and 802.3at AP7110DN-AGN: PoE function in compliance with IEEE 802.3at |
| Maximum power consumption | AP7110DN-AGN: 15.7 W AP7110SN-GN: 8.7 W NOTE:The maximum power consumption depends on local laws. |
|
| Environment parameters | Operating temperature | -10°C to +55°C |
| Storage temperature | -40°C to +70°C | |
| Humidity | 5% to 95% (non-condensing) | |
| Waterproof grade | IP41 | |
| Altitude | –60 m to 4000 m | |
Radio Specifications
| Item | Description | ||||
|---|---|---|---|---|---|
| Antenna type | Removable RP-SMA antenna | ||||
| Antenna gain | AP7110DN-AGN 2.4 GHz: 2.5 dBi 5 GHz: 4 dBi AP7110SN-GN: 2.5 dBi |
||||
| Maximum number of concurrent users |
≤256 | ||||
| Maximum transmit power |
20dBm You can adjust the transmit power from the maximum transmit power by 20 dB, with a step of 1 dB. NOTE:Actual transmit power depends on local laws and regulations. |
||||
| Maximum number of non-overlapping channels for AP7110DN-AGN | 2.4 GHz 802.11b/g 20MHz: 3 802.11n 20MHz: 3 40MHz: 1 |
5 GHz 802.11a 20MHz: 24 802.11n 20MHz: 24 40MHz: 11 |
|||
| NOTE:The number of non-overlapping channels allowed varies in different countries. For details, see the Country codes & Channels compliance status | |||||
| Maximum number of non-overlapping channels for AP7110SN-GN | 802.11b/g 20MHz: 3 802.11n 20MHz: 3 40MHz: 1 |
||||
| NOTE:The number of non-overlapping channels allowed varies in different countries. For details, see the Country codes & Channels compliance status | |||||
| Channel Rate | 802.11b: 1, 2, 5.5, and 11 Mbit/s | ||||
| 802.11g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/s | |||||
| 802.11n data rate: AP7110DN-AGN: 2.4 GHz and 5 GHz AP7110SN-GN: 2.4 GHz | |||||
| GI2=800ns | GI=400ns | ||||
| 20 MHz (Mbit/s) | 40 MHz (Mbit/s) | 20 MHz (Mbit/s) | 40 MHz (Mbit/s) | ||
| 6.5 @ MCS10 | 13.5 @ MCS0 | 7.2 @ MCS0 | 15 @ MCS0 | ||
| 13 @ MCS1 | 27 @ MCS1 | 14.4 @ MCS1 | 30 @ MCS1 | ||
| 19.5 @ MCS2 | 40.5 @ MCS2 | 21.7 @ MCS2 | 45 @ MCS2 | ||
| 26 @ MCS3 | 54 @ MCS3 | 28.9 @ MCS3 | 60 @ MCS3 | ||
| 39 @ MCS4 | 81 @ MCS4 | 43.3 @ MCS4 | 90 @ MCS4 | ||
| 52 @ MCS5 | 108 @ MCS5 | 57.8 @ MCS5 | 120 @ MCS5 | ||
| 58.5 @ MCS6 | 121.5 @ MCS6 | 65 @ MCS6 | 135 @ MCS6 | ||
| 65 @ MCS7 | 135 @ MCS7 | 72.2 @ MCS7 | 150 @ MCS7 | ||
| 13 @ MCS8 | 27 @ MCS8 | 14.4 @ MCS8 | 30 @ MCS8 | ||
| 26 @ MCS9 | 54 @ MCS9 | 28.9 @ MCS9 | 60 @ MCS9 | ||
| 39 @ MCS10 | 81 @ MCS10 | 43.3 @ MCS10 | 90 @ MCS10 | ||
| 52 @ MCS11 | 108 @ MCS11 | 57.8 @ MCS11 | 120 @ MCS11 | ||
| 78 @ MCS12 | 162 @ MCS12 | 86.7 @ MCS12 | 180 @ MCS12 | ||
| 104 @ MCS13 | 216 @ MCS13 | 115.6 @ MCS13 | 240 @ MCS13 | ||
| 117 @ MCS14 | 243 @ MCS14 | 130 @ MCS14 | 270 @ MCS14 | ||
| 130 @ MCS15 | 270 @ MCS15 | 144.4 @ MCS15 | 300 @ MCS15 | ||
| 19.5 @ MCS16 | 40.5 @ MCS16 | 21.7 @ MCS16 | 45 @ MCS16 | ||
| 39 @ MCS17 | 81 @ MCS17 | 43.3 @ MCS17 | 90 @ MCS17 | ||
| 58.5 @ MCS18 | 121.5 @ MCS18 | 65 @ MCS18 | 135 @ MCS18 | ||
| 78 @ MCS19 | 162 @ MCS19 | 86.7 @ MCS19 | 180 @ MCS19 | ||
| 117 @ MCS20 | 243 @ MCS20 | 130 @ MCS20 | 270 @ MCS20 | ||
| 156 @ MCS21 | 324 @ MCS21 | 173.3 @ MCS21 | 360 @ MCS21 | ||
| 175.5 @ MCS22 | 364.5 @ MCS22 | 195 @ MCS22 | 405 @ MCS22 | ||
| 195 @ MCS23 | 405 @ MCS23 | 216.7 @ MCS23 | 450 @ MCS23 | ||
| NOTE:Modulation coding scheme (MCS) index: determines the spatial flow quantity, modulation, coding rate, and data rate. Guard interval (GI): indicates the period in nanoseconds the radio listens between packets. | |||||
| Receiver sensitivity of the AP7110DN-AGN | 2.4 GHz 802.11b (CCK) -97 dBm @ 1 Mbit/s -92 dBm @ 2 Mbit/s -93 dBm @ 5.5 Mbit/s -89 dBm @ 11 Mbit/s |
2.4 GHz 802.11g (non-HT20) -93 dBm @ 6 Mbit/s -90 dBm @ 9 Mbit/s -90 dBm @ 12 Mbit/s -88 dBm @ 18 Mbit/s -84 dBm @ 24 Mbit/s -81 dBm @ 36 Mbit/s -77 dBm @ 48 Mbit/s -74 dBm @ 54 Mbit/s |
2.4 GHz 802.11n (HT20) -93 dBm @ MCS0 -90 dBm @ MCS1 -88 dBm @ MCS2 -82 dBm @ MCS3 -79 dBm @ MCS4 -75 dBm @ MCS5 -73 dBm @ MCS6 -72 dBm @ MCS7 -87 dBm @ MCS8 -86 dBm @ MCS9 -86 dBm @ MCS10 -83 dBm @ MCS11 -79 dBm @ MCS12 -75 dBm @ MCS13 -74 dBm @ MCS14 -73 dBm @ MCS15 -87 dBm @ MCS16 -86 dBm @ MCS17 -86 dBm @ MCS18 -83 dBm @ MCS19 -79 dBm @ MCS20 -75 dBm @ MCS21 -74 dBm @ MCS22 -73 dBm @ MCS23 |
2.4 GHz 802.11n (HT40) -86 dBm @ MCS0 -86 dBm @ MCS1 -84 dBm @ MCS2 -80 dBm @ MCS3 -77 dBm @ MCS4 -72 dBm @ MCS5 -70 dBm @ MCS6 -68 dBm @ MCS7 -86 dBm @ MCS8 -86 dBm @ MCS9 -84 dBm @ MCS10 -80 dBm @ MCS11 -77 dBm @ MCS12 -72 dBm @ MCS13 -71 dBm @ MCS14 -70 dBm @ MCS15 -86 dBm @ MCS16 -86 dBm @ MCS17 -84 dBm @ MCS18 -80 dBm @ MCS19 -77 dBm @ MCS20 -72 dBm @ MCS21 -71 dBm @ MCS22 -70 dBm @ MCS23 |
|
| 5 GHz 802.11a (non-HT20) -93 dBm @ 6 Mbit/s -90 dBm @ 9 Mbit/s -89 dBm @ 12 Mbit/s -86 dBm @ 18 Mbit/s -83 dBm @ 24 Mbit/s -80 dBm @ 36 Mbit/s -75 dBm @ 48 Mbit/s -74 dBm @ 54 Mbit/s |
5 GHz 802.11n (HT20) -93 dBm @ MCS0 -88 dBm @ MCS1 -86 dBm @ MCS2 -81 dBm @ MCS3 -78 dBm @ MCS4 -74 dBm @ MCS5 -72 dBm @ MCS6 -71 dBm @ MCS7 -89 dBm @ MCS8 -86 dBm @ MCS9 -84 dBm @ MCS10 -80 dBm @ MCS11 -77 dBm @ MCS12 -72 dBm @ MCS13 -70 dBm @ MCS14 -69 dBm @ MCS15 -89 dBm @ MCS16 -86 dBm @ MCS17 -84 dBm @ MCS18 -80 dBm @ MCS19 -77 dBm @ MCS20 -72 dBm @ MCS21 -70 dBm @ MCS22 -69 dBm @ MCS23 |
5 GHz 802.11n (HT40) -87 dBm @ MCS0 -85 dBm @ MCS1 -83 dBm @ MCS2 -79 dBm @ MCS3 -75 dBm @ MCS4 -71 dBm @ MCS5 -68 dBm @ MCS6 -67 dBm @ MCS7 -86 dBm @ MCS8 -83 dBm @ MCS9 -81 dBm @ MCS10 -76 dBm @ MCS11 -73 dBm @ MCS12 -69 dBm @ MCS13 -68 dBm @ MCS14 -66 dBm @ MCS15 -86 dBm @ MCS16 -83 dBm @ MCS17 -81 dBm @ MCS18 -76 dBm @ MCS19 -73 dBm @ MCS20 -69 dBm @ MCS21 -68 dBm @ MCS22 -66 dBm @ MCS23 |
|||
| Receiver sensitivity of the AP7110SN-GN | 802.11b (CCK): -97 dBm @ 1 Mbit/s -92 dBm @ 2 Mbit/s -93 dBm @ 5.5 Mbit/s -89 dBm @ 11 Mbit/s |
802.11g (non-HT20): -93 dBm @ 6 Mbit/s -90 dBm @ 9 Mbit/s -90 dBm @ 12 Mbit/s -88 dBm @ 18 Mbit/s -84 dBm @ 24 Mbit/s -81 dBm @ 36 Mbit/s -77 dBm @ 48 Mbit/s -74 dBm @ 54 Mbit/s |
802.11n (HT20): -93 dBm @ MCS0 -90 dBm @ MCS1 -88 dBm @ MCS2 -82 dBm @ MCS3 -79 dBm @ MCS4 -75 dBm @ MCS5 -73 dBm @ MCS6 -72 dBm @ MCS7 -87 dBm @ MCS8 -86 dBm @ MCS9 -86 dBm @ MCS10 -83 dBm @ MCS11 -79 dBm @ MCS12 -75 dBm @ MCS13 -74 dBm @ MCS14 -73 dBm @ MCS15 -87 dBm @ MCS16 -86 dBm @ MCS17 -86 dBm @ MCS18 -83 dBm @ MCS19 -79 dBm @ MCS20 -75 dBm @ MCS21 -74 dBm @ MCS22 -73 dBm @ MCS23 |
802.11n (HT40): -86 dBm @ MCS0 -86 dBm @ MCS1 -84 dBm @ MCS2 -80 dBm @ MCS3 -77 dBm @ MCS4 -72 dBm @ MCS5 -70 dBm @ MCS6 -68 dBm @ MCS7 -86 dBm @ MCS8 -86 dBm @ MCS9 -84 dBm @ MCS10 -80 dBm @ MCS11 -77 dBm @ MCS12 -72 dBm @ MCS13 -71 dBm @ MCS14 -70 dBm @ MCS15 -86 dBm @ MCS16 -86 dBm @ MCS17 -84 dBm @ MCS18 -80 dBm @ MCS19 -77 dBm @ MCS20 -72 dBm @ MCS21 -71 dBm @ MCS22 -70 dBm @ MCS23 |
|
