Cisco Asr Router ASR1002

Cisco Asr Router ASR1002 thumbnail-1
Cisco Asr Router ASR1002 photo-1
US$ 1 - 8,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Wired
Function:
Firewall, QoS, VPN
Contact Supplier Request Quote Chat Now
Shanghai Chu Cheng Information Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type Wired
Function Firewall, QoS, VPN
Certification CE,EMC
Brand Name CISCO
Model Number ASR1002

Specifications

1. four built-in Gigabit Ethernet ports
2.Configurable with 5 Gbps or 10 Gbps embedded services processor


Product Description



The Cisco ASR 1002 Router in a 2-rack unit (RU) form factor comes with an integrated route and serial interface processors. It houses three shared port adapter (SPA) slots supporting single height and dual height SPAs. Configurable with either the 5 Gbps or 10 Gbps embedded services processor and four built-in gigabit Ethernet ports, it is an ideal solution for a large branch office or as a managed high-speed customer premises equipment (CPE) device to support enhanced features such as security, deep packet inspection, and firewall.

Running on Cisco IOS XE Software, the Cisco ASR 1002 router supports software redundancy without redundant hardware.cisco asr router ASR1002cisco asr router ASR1002


PRODUCT DETAILS
Device Type Router - with Cisco ASR 1000 Series Embedded Services Processor, 5Gbps
Enclosure Type Desktop - modular - 2U
Remote Management Protocol SNMP, Telnet, SSH
Power AC 120/230 V ( 50/60 Hz )
Dimensions (WxDxH) 43.7 cm x 55.6 cm x 8.9 cm

GENERAL
Device Type Router - with Cisco ASR 1000 Series Embedded Services Processor, 5Gbps
Enclosure Type Desktop - modular - 2U
Connectivity Technology Wired
Remote Management Protocol SNMP, Telnet, SSH
Features VPN support, MPLS support, IPv6 support, Stateful switchover (SSO), MPLS VPN
Compliant Standards CISPR 24, EN55022, VCCI Class A ITE, EN55024, CISPR 22, EN50082-1, CSA 22.2 No. 60950, EN 61000-6-1, AS/NZS 60950-1, AS/NZ 3548 Class A, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1
RAM 4 GB
EXPANSION / CONNECTIVITY
Interfaces Management : 1 x 10Base-T/100Base-TX - RJ-45
Management : 1 x console - RJ-45
Management : 1 x auxiliary - RJ-45
4 x SFP (mini-GBIC)
Expansion Slots 3 (total) / 3 (free) x expansion slot
1 (total) / 0 (free) x processor board
Installed Modules Qty (Max) 1 (installed) / 4 (max)
POWER
Power Device Internal power supply
Power Redundancy Yes
Installed Qty 2 (installed) / 2 (max)
Voltage Required AC 120/230 V ( 50/60 Hz )
MISCELLANEOUS
Rack Mounting Kit Included
SOFTWARE / SYSTEM REQUIREMENTS
OS Provided Cisco IOS Advanced Enterprise Services
DIMENSIONS & WEIGHT
Width 43.7 cm
Depth 55.6 cm
Height 8.9 cm
ENVIRONMENTAL PARAMETERS
Min Operating Temperature 5 °C
Max Operating Temperature 40 °C
Humidity Range Operating 5 - 90%
