Manual Rotation Stage, diameter 82mm
Manual Rotation Stage, manual rotary stage, rotary translation stage, manual rotation table/ 82mm
Production Feature:
*The table top can rotate in 360°
*The stage can rotate in +/-10°for fine adjustment. Micrometer head drive and spring reverse motion for high resolution and without backlash.
*The stage with regular holes both on top and bottom for connecting the other stages
Model Number |
J01SX82 |
Diameter of Table |
82mm |
Drive |
Micrometer Head |
Adjustment Range |
Rough Adjust 360°, Fine Adjust +/-10° |
Min Score |
1° |
Min Reading |
2’ |
Min Adjustment |
15” |
Loading |
5kg |
Run-out of Top Plate |
60μm |
Eccentricity |
30μm |
Degree of Parallelization |
60μm |
Weight |
0.5kg |
Material |
Aluminum |
Surface |
Black-Anodized |
