Manual Rotation Stage, Manual Rotary Stage, Rotary Translation Stage, Manual Rotation Table/ 100mm
Manual Rotation Stage, diameter 100mm
Production Feature:
*The table top can rotate in 360°
*Worm Gear design for high loading and accuracy
*The stage with regular holes both on top and bottom for connecting the other stages
Model Number |
J02SX100 |
Diameter of Table |
100mm |
Drive |
Worm Gear |
Adjustment Range |
360° |
Min Score |
2° |
Min Reading |
12’ |
Min Adjustment |
36” |
Loading |
15kg |
Run-out of Top Plate |
30μm |
Eccentricity |
15μm |
Degree of Parallelization |
30μm |
Weight |
0.5kg |
Material |
Aluminum |
Surface |
Black-Anodized |
