Home > Instruments & Meters > Optical Lens & Instrument > Optical Lens > Tilt Device, Angular Adjustment and Tilt Stage, Angular Adjustment
Tilt Device, Angular Adjustment and Tilt Stage, Angular Adjustment
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2012
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Goniometer Stages, Goniometer Table, Goniometric Stages, Manual Goniometer Stage, Goniometer Moving Stage/+/-10NegotiableMOQ: 1 -
Manual Goniometer Stage, Goniometer Moving Stage, Manual Positioning Stages, Positioning Tables, Manual Stage +/-10NegotiableMOQ: 1
-
Goniometer Stages, Goniometer Table, Goniometric Stages, Manual Positioning Stages, Positioning Tables, Manual Stage +/-10NegotiableMOQ: 1
-
Goniometer Stages, Goniometer Table, Goniometric Stages, Manual Positioning Stages, Positioning Tables, Manual Stage +/-15NegotiableMOQ: 1
-
xy Manual Goniometer Stage, xy Goniometric Stage, Goniometer Table, Goniometric Table, Goniometer Translate StageNegotiableMOQ: 1
Manual Goniometer Stage, Angle Range +/-15°
tilt device, angular adjustment and tilt stage, angular adjustment
Production Feature:
*The stage can rotate in small angle
*Dovetail guide design for high loading and accuracy
*The rotation center will be same when it use together with 05SJ15
*Wheel screw can fix the position
*The stages with regular holes for combine with other products easily
Model Number |
J04SJ15 |
Dimension |
65mm x 65 mm |
Angle Range |
+/-15° |
Height of Rotary Center |
50 mm |
Deviation of Rotary Center |
0.05 mm |
Drive |
Worm Gear |
Guide |
V Guide + ball screw |
Position of Drive |
In center |
Min Scale |
1° |
Min Reading |
5’ |
Min Adjustment |
30” |
Deflection |
200” |
Tilt |
200” |
Loading |
6kg |
Weight |
0.46kg |
Material |
Aluminum |
Surface Treatment |
Black-Anodized |
