Manual Goniometer Stage, Angle Range +/-10°
manual goniometer stage, goniometer moving stage, manual positioning stages, positioning tables, manual stage +/-10
Production Feature:
*The stage can rotate in small angle
*Dovetail guide design for high loading and accuracy
*The rotation center will be same when it use together with 01SJ10
*Wheel screw can fix the position
*The stages with regular holes for combine with other products easily
Model Number |
J02SJ10 |
Dimension |
65mm x 65 mm |
Angle Range |
+/-10° |
Height of Rotary Center |
76 mm |
Deviation of Rotary Center |
0.1 mm |
Drive |
Worm Gear |
Guide |
Dovetail Guide |
Position of Drive |
In center |
Min Scale |
1° |
Min Reading |
5’ |
Min Adjustment |
30” |
Deflection |
200” |
Tilt |
200” |
Loading |
6kg |
Weight |
0.46kg |
Material |
Aluminum |
Surface Treatment |
Black-Anodized |
