Specifications
Anti-agingAnti-acid and alkaline
Homogenous structure
Cellular confinement system (geocell)
GEOCELL INTRODUCTION
Cellular confinement system (geocell) is a system of smooth, surface-patterned (textured) or perforated PE–HD strips (50, 75, 100, 150, 200, 250, 300 mm in depth) connected in a series with collateral root penetrations vertical to the longitudinal axis.
After dilatation and stabilization, the connected strips form walls of spatial flexible cells. Subsequently, these cells are filled with filling material (chosen according to the purpose of use and surface load): sand, gravel, earth, crushed stone, concrete, refuse excavated from the construction site, etc.
The geocell confinement system is suitable for
• Cut or fill embankments
• Dams or spillways
• Revetments
• Abutment protection
• Geomembrane protection
• Soil-nailing cove
• Landfill capping
Properties:
Anti-aging
Anti-acid and alkaline
Homogenous structure
The best sidewise restriction and fixation
Easy for construction
Packing
Length: 4-7m
Specification
|
Geocell |
High strength geocell |
|
Tensile strength of sheet materials , Mpa |
≥ 23 (PP) |
≥ 20 (PE) |
≥ 200 |
|
Tensile strength for welded seam , N / cm |
≥ 100 (PP) |
≥ 100(PE) |
≥ 150 |
Welding distance , mm |
330-550 |
||
Stretched size m x m |
4 x5 - 6x 7 |
||
