SZ-BF100 Electrical spark tungsten carbide rod metal coating machine increase metal hardness
1.Parameters:
Model |
SZ-BF100 |
Input voltage |
AC220V 50/60HZ |
Discharge Options |
6 speed switch |
Output power |
100VA |
Coating thickness |
0.01mm-0.03mm |
Coating speed |
1cm2/40s |
Net Weight |
9KG |
Dimension |
330*270*160MM |
Round bar
Φ0.5x40mm , Φ0.8x40mm , Φ1.0x40mm , Φ1.5x40mm ,
Φ2.0x40mm , Φ3.0x40mm
Square bar
1.5x2x40mm , 1.5x3x40mm , 2x4x40mm
3. Application range:
3.1 Widely used for impact resistance molds, like stamping moulds, casting moulds, injections moulds, and other plastic metal moulds. It can increase about 200%-300% life expectancy of moulds.
3.2 It also can be used for high temperature resistant surface, like die casting and aluminum die casting surface, which can increase about 200%-300% life expectancy.
3.3 It also can be used for coating all kinds of cutting tools, like lathe tools, drills, milling cutters and all kinds of metal cutting tools, which can increase about 300%-500% life expectancy.
3.4 Used for surface coating of various clamps, chucks, which can increase wear resistance and prolong service life.
4.CHARACTERISTICS
4.1 Electrical spark tungsten carbide hardening coating machine can coat super hard tungsten carbide alloy to the surface of working parts, and penetrate into the working surface. So it can increase the coating surface of heat resistance, resistance to impact and abrasion resistance. The maximum coating thickness of tungsten carbide alloy can reach to 0.03mm; the coating surface hardness can reach to HV1100-HV1400(HRC70-72°). There are six kind of thickness can be adjusted.
4.2 This machine use high speed embedded processor as the master control chip, and it can control each degree discharge current precisely and change degree fast and working quite stable. The design on large current circuit and signal control circuit are isolated, isolation degree reach to more than 2500V, which greatly increase the stability of machine’s working.
4.3 After hardening, micro-hardness can be obtained HV1100-1400(equivalent to HRC70°-72°). When use YGB hard alloy as electrode to strengthen mould steel material, the layer hardness is up to or over HV1200, equivalent to over HRC72°. When the heat reached to 700-800°, red hardness remains unchanged, so as to improve the surface wear resistance of the work pieces; extend the service life of corrosion resistance over 1-3 times.
4.4 Intensifying process just doing under common temperature, spark discharge process finished instantaneously, so there is no deformation and cracks of the work pieces; and the intensified layer infiltrate into the base of work pieces, combined strong and no peel and fall off. The layer of strengthened surface is smooth, and usually no need do polishing again.
4.5 The equipment is light and consumes few electrode, operating is simple and portable, working process flexible and fast with a wide application range.
