Specifications
1.The newest development of the CNC contour cutting machine.2.with stepper servo motor,computer control
3.revolving blade
ERS - CNC03 Computerized CNC Contour Cutting Polyurethane Sponge Latex Memory Foam Machine
The machine is our newest development of the CNC contour cutting machine, adopts PC computer + multi-axis motion control card system,and using the 6mm width serrated circular cutter two or three dimensional polyurethane foam or similar materials, Cutting precise, operate easily, so the product widely used for varies field, such as heat preservation materials, furniture, mattress, packing, Air conditioning and ventilation pipes ,other industrial usage.
Technical Specification:
1.Maximum cutting size:W2000*L2000*H1200MM Cutting precision:±0.20MM
2.Processing Speed: 0-10 m / min adjustable timely
3.Cutting method: circular blade cutting
4.blade t speed: stepless 0-1200 m / min adjustable
5.Blade speed: stepless 0-1200 m / min adjustable
6.Software: YCUT special foam cutting system
7. the motor control system using stepper servo system
8. control systen: PC computer + multi-axis motion control card
9. blade specifications: L11900 * W3 * 0.6MM circular blade
10.Total power: 6KW
11.External dimensions: L5000 * W4000 *H3000MM
