Pvc PvgSolid woven conveyor belt

Solid woven conveyor belt is a kind of traditional rubber belt, which is constructed by solid woven. It is reliable to transportation for short and medium distance, it is flexible, heavy duty and high speed. Now fabric belt is preferred to using by mining, seaport, construction, metallurgy, chemical and grain transportation.

Classification of product:

1.Non pressed  PVC type
After dipping with PVC paste on the soild woven fabric,add PVC cover on the solid carcass to form the belt.
2.PVG type
Based on the non pressed PVC type,the carcass is covered with top and bottom covers composed mainly of rubber.the belt is then formed after being pressed.

construction features and applications:
1.The belt has good flame resistant and anti-static properties.it can fully satisfy the requirements of MT-914 and is especially suitable for material conveying at inflammable conditions of underground coal mines.
2.The solid woven fabric uses high tensile strength and low elongation polyester long filament as warp fibre,for weft fibre,it uses high tensile and medium modulus nylon filament.The fabric is high in strength,low in elongation,light in carcass,free of separation of plies,shock resistant,anti-tear and good in troughability.
3.Non pressed PVC type is suitable for applications in dry conditions at a slope angle of no greater than 16 degrees.PVG type is suitable for applications in wet conditions at a slope angle of less than 20 degrees.
4.PVG type is covered with covers mainly composed of rubber,which further improves the troughability,resistance to wetness and slip,resistance to low temperature,elongation and wear resistance of the belt.Thus it can not only enhance the slope angle of conveying but also elongate life of belt.

TECHNICAL SPECIFICATIONS FOR REFERENCE:

Recommenfed minimum pulley diameter:

Except good raw material, good production equipments and technology, the safe and user-friendly packing is also very important for sidewall belting. HYRUBBERS have been packing conveyor belt in standard way to ensure the belt is safe during transportation and storage period.

packaging:packed in rolls and covered by fabric water-proof cloth,or clients' requirement also be respected

shipping:within 10-20 days,or depends on the quantity

HYRUBBERS CO.,LTD is specializing In manufacturing, exporting and developing conveyor belt, in the same time rubber sheet, rubber tiles and so on.

The factory founded has 260 people including 220 workers, and 15 engineers and technicians, 25international sales workers, covering an area of 50000 m2, owing 220 sets of main production equipment.

The ISO9001: 2000 certified factory has established a stable and reliable quality control system with a modem management.

Now with the export quantity larger and larger, we become one of the biggest manufacture in North of China.

 Why you choose us?

1.Super high quality.

2.Competitive price.

3.Good producing equipment and technology.

4.Large production ability.

5.Prompt delivery.

6.Small order accepted.

7.Excelent sale and after-sale service.

8.OEM available.

Is the product sample available?

Yes,all product samples are available for you to test the quality.

Is OEM available?

Yes,OEM is available.We have professional designer to help your brand promotion.

Are the products tested before shipping?

Yes,all of our products were qualified before leave the factory,we test every batch every day.

Delivery details?

Within 10-20 days in general or depends on quality of the order.

Packaging details?

Packed in rolls and covered by nylon water proof cloth.Clients' requirement are also respected.

What's the quality guarantee?

We have totally quality guarantee to customers,we will be responsible for any quality problems.
