Specifications
1:Fast speed than handle making2:Computer control easy for complex design
3:The certificate of CE,SGS,FDA
2. Only manufacturer adopts square tube framework machine body 40% higher than simple iron sheet structure, never distortion. Prevents machine from quivering and resonance during long time work.
3. High efficiency tube with stable laser path, life time reaches to 10000 hours.
4. Red cross point offers highest accuracy position.
6. Transparent acrylic watching door, easy checking work process.
7. Professional motion control card offers continue fast curve cutting together with shortest path selection. Shorten work time.
Technical Parameters
Model |
BCL1006X |
BCL1309X |
BCL1610X |
BCL1812X |
Option |
Working Area |
1000*600mm |
1000*600* |
1300*900mm |
1800*1200mm |
Accordingtodemands |
Laser Power |
60w/80w/100w/130w//150w |
||||
Laser Type |
CO2 Sealed Laser Tube,10.6μm |
||||
Cooling Type |
Water Cooling |
||||
Engraving Speed |
0-60000mm/min |
||||
Cutting Speed |
0-40000mm/min |
||||
Laser Output Control |
0-100% Set by Software |
||||
Min.Engraving Size |
Chinese:2.0mm*2.0mm,English Letter:1.0mm*1.0mm |
||||
Highest Scanning Precision |
4000DPI |
||||
Locating Accuracy |
≤+0.01mm |
||||
Controlling Software |
DSP Control System |
||||
Graphic Format Supported |
DST PLT BMP DXF DWG AI LAS,etc |
||||
Compatible Software |
CORELDRAW,PHOTOSHOP,AUTOCAD,TAJIMA,etc. |
||||
Color Separation |
Yes |
||||
Drive System |
High-precision 3-phase Stepper Motor |
||||
Auxiliary Equipments |
Exhaust Fan and Air Exhaust Pipe |
||||
Power Supply |
AC110V/220V+10%,50HZ/60HZ |
||||
Working Environment |
Temperature:0-45C,Humidity:5-95%(No Condensate Water) |
||||
Packing Size |
According to the Model |
||||
Net Weight |
According to the Model |
||||
Option |
Honeycomb Worktable,Rotary Device,Auto-focus Device |
||||
APPLICATIONS:
Non-metal:Acrylic,wood(balsawood,paulownia),double-color board,ABS board,rubber,plastic,glass and so on.
Mould industry(construction mould,aviation and navigation mould,wooden mould),advertising,decoration,arts and crafts,electronics,electric appliances,etc
COMPANY INFORMATION:
PARAPPLICATION:
Gaurantee and after sale service:
Gurantee the whole machine for 2 YEARS and laser tube for 3 months; offer lifelong repair; laser tube’s average life is 4000-10000 working hours(depends on the laser power); Offer 24 - hour technical support.
