Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Cutting Machine > Chia Jinan Bodor Co2 Laser Cutting Bed BCL-BC With Dust -proof and Smoke-proof Function

Chia Jinan Bodor Co2 Laser Cutting Bed BCL-BC With Dust -proof and Smoke-proof Function

Chia Jinan Bodor Co2 Laser Cutting Bed BCL-BC With Dust -proof and Smoke-proof Function thumbnail-1
Chia Jinan Bodor Co2 Laser Cutting Bed BCL-BC With Dust -proof and Smoke-proof Function photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
CO2
Applicable Material:
Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Wood
Contact Supplier Request Quote Chat Now
Jinan Bodor CNC Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai Guangzhou Ningbo Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Laser Type CO2
Applicable Material Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Wood
CNC or Not Yes
Cooling Mode Water Cooling
Graphic Format Supported AI, PLT, DXF, BMP, DST, DWG, LAS, DXP
Place of Origin Shandong, China
Brand Name Bodor
Model Number BCL-BC
Certification CE, SGS, Other, CE, SGS, FDA
After-sales Service Provided Engineers available to service machinery overseas

Specifications

dust-free processing standard
large format materials processing
fully opened stainless steel working platform






Product Description



Main Features

1.The dust-proof and smoke- proof feature Bodor designed protects equipment from external pollution.Meanwhile,to avoid polluting inside structure because of smoke dust or wastes during processing.
2. To satisfy the needs to cut off large size of processing materials, the BD-series adopts stable solid chassis to keep stability and precision during moving.
3. Moving system choose linear guide rails, precision gear and rack driven to ensure the machine' s accuracy.
4. Using the special treatment of all open stainless steel mesh working platform, convenient operation, never wear.
5. Red dot position device,which indicates rightly the processing position to save time.

Technical Parameter
Model BCL1325BC BCL1625BC BCL1830BC BCL2030BC BCL2060BC Option
Working Area 1300*2500mm 1600*2500mm 1800*3000mm 2000*3000mm 2000*6000mm According to Demands
Laser Power 60w/80w/100w/130w/150w
Laser Type Sealed Co2 Laser Tube,10.6μm
Cooling System Water Cooling
Cutting Speed 0—30000mm/min
Laser Output Control 0-100% Software Setting
Smallest Character Engraving Chinese English2.0*2.0mm,1.0*1.0mm
Highest Scanning Precision 4000DPI
Locating Precision ≤+0.01mm
Controlling Software DSP Control System
Graphic Format Supported DST PLT BMP DXF DWG AI LAS,etc
Compatible Software TAJIMA,CORELDRAW,PHOTOSHOP,AUTOCAD,All Type of AUTOCAD Software in Cloth
color Separation Yes
Drive System High-precision 3-phase Stepper Motor
Auxiliary Equipments Exhaust Fan and Air Exhaust Pipe
power Supply AC110V/220V+10%,50HZ/60HZ
Optional Parts Up and Down Worktable(Length:500mm;Highness:350mm ),Honeycomb Worktable,Rotary Device,Auto-focus Device,etc.



Applications

Garments sampling, large format tailoring ,leather industry ,shoemaking ,decoration,furniture ,advertisement, packing and printing ,molding and artcrfts industries,etc.
Fabrics,cloth, laser, paper, bamboo ware, acryl, glass, thin film and canvas, etc.

Packaging & Shipping




Our Services

  Chia Jinan Bodor Co2 Laser Cutting Bed BCL-BC with dust -proof and smoke-proof function



Warranty and after sale service:



Warranty the whole machine for 2 YEARS and laser tube for 4 months; offer lifelong repair; laser tube’s

average life is 4000-10000 working hours(depends on the laser power); Offer 24 - hour technical support




Company Information



About Bodor

Jinan Bodor CNC Machine Co.,Ltd has been always devoting to the research and manufacturing of the CNC products such as Cutting, Engraving and Marking Machines and so on.Today, Bodor CNC has developed to a large worldwide Manufacturing Group, and becomes an excellent leader of the world in this field.

Bodor CNC was founded in 2002, and changed its name to "bodor" formly in 2008.We can supply Laser Cutting, Engraving and Marking Machines,Dot Peen Marking Machines, and many other industrial automation equipments.Meanwhile,we can also supply industrial automation sulutions according to your special needs.

Bodor CNC has earned ourselves a good reputation and ten thousands of faithful customers with our advanced technology,standardized producing management,stable products,and the best services.Through years of international marketing experience,we have established business relationships with customers from North America,West Europe,South Asia,and Middle East,etc.Welcome to join the world of Bodor CNC,you can experience the world-class products and services together with our customers all over the world.
