Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Cutting Machine > Drawing Pen Laser Cutting Machine Price
Drawing Pen Laser Cutting Machine Price
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
CO2
Applicable Material:
Acrylic, Leather, Paper, Plexiglax, Plywood, Rubber
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO TIANJIN SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Drawing Pen Fabric Laser Engraving Cutting MachineNegotiableMOQ: 1 Set -
1325 Laser Cutting BedNegotiableMOQ: 1 Set
-
Cloth Cutting Machine With 80w Laser TubeNegotiableMOQ: 1 Set
-
China Bodor Cloth Laser Engraving MachineNegotiableMOQ: 1 Set
-
CO2 Used Laser Engraver for SaleNegotiableMOQ: 1 Set
Condition
New
Laser Type
CO2
Applicable Material
Acrylic, Leather, Paper, Plexiglax, Plywood, Rubber
CNC or Not
Yes
Cooling Mode
Water Cooling
Control Software
Laser work 5
Graphic Format Supported
AI, DWG, DXF, LAS, PLT
Place of Origin
China
Brand Name
Bodor
Model Number
BCL
Certification
CE, SGS
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Stable and solid chassisHigh precision ball screw
Equipped with advanced DSP control servo motor and reducer
Main Features
Drawing pen function can be installed into our high precision laser cutting and engraving machines, so it has has both the characteristics of both machine series. In addtion, the newly added drawing pen function can also achieve automatic painting and drawing, which highly increases the working efficiency. When the size of cutting materials’ is small with big amount, drawing pen function can mark before materials’ cutting, which could assure sequance in an orderly way and improve working efficiency.
Technical Parameter
| Machine Series | X Series(Optional) | B Series(Optional) | |||||
| Model | BCL1006X | BCL1309X | BCL1610XH | BCL1812XH | BCL 1325B | BCL 1630BH | BCL 1830BH |
| Working Area | 1000*600mm | 1300*900mm | 1600*1000mm | 1800*1200mm | 1300*2500mm | 1600*3000mm | 1800*3000mm |
| Locating Accuracy | ≤+0.01mm | 0.02mm | |||||
| Cutting Speed | 0---40000mm/min | 0—30000mm/min | |||||
| Laser Output Control | 1-100% Set by Software ) | 0-100% adjust freely | |||||
| Drawing Pen Function | add drawing pen function according to demands, then the X axis wide will scale back around 100 mm | ||||||
| Laser Power | 60w/80w/100w/130w/150w | ||||||
| Laser Type | CO2 Sealed Laser Tube ,Water Cooling, 10.6μm | ||||||
| Cooling Type | Water Cooling | ||||||
| Min. Engraving Size | Chinese: 2.0mm*2.0mm, English Letter:1.0mm*1.0mm | ||||||
| Highest Scanning Precision | 4000DPI | ||||||
| Graphic Format Supported | DST PLT BMP DXF AI DSB BMP GIF JPEG PNG ICON CURSOR TIFF TGA PCX WBMP WMF EMF JBG PGX, etc | ||||||
| Color Separation | Yes | ||||||
| Power supply | AC110V/220V+10%,50HZ/60HZ | ||||||
| Drive System | High-precision 3-phase Stepper Motor | ||||||
| Option | Up-down table,Honeycomb platform,Rotary device,Auto-focus Device | ||||||
Applications
Applicable materials:
cloth (lantern cloth), leather, paper, canvas, etc
Applicable industry:
the apparel industry, leather industry, shoe industry, advertising industry, craft gifts industry, etc.
the apparel industry, leather industry, shoe industry, advertising industry, craft gifts industry, etc.
Applicable materials:
cloth (lantern cloth), leather, paper, canvas, etc
