Help CenterMulti-function Water Well Drill KW10 Hot Sale
Related Products
-
Multi-function Water Well Drill KW20 Hot SaleUS$ 40,000 - 50,000MOQ: 1 Piece -
KW30 Portable Water Drilling EquipmentUS$ 40,000 - 50,000MOQ: 1 Set
-
2012 Hot Sale !!depth 120-300m, Diameter:168-300mm,KW30 High-Effect Hydraulic Geothermal Water Well Drilling RigsUS$ 40,000 - 50,000MOQ: 1 Set
-
New One !!depth 120-300m, Diameter:168-300mm,KW30 High-Effect Hydraulic Geothermal Water Well Drilling RigsUS$ 40,000 - 50,000MOQ: 1 Set
-
KW30 Portable Water Drilling Equipment/Crawler Water Drilling Rig EquipmentUS$ 40,000 - 50,000MOQ: 1 Set
Specifications
1.Double motor rotary mechanism2.Double Oil Cylinders feeding
3.Safe and stable travelling
4,factory price
5.100 pc/week
1)type:crawler
2)diameter:115-254mm
3)depth:120m
Crawler rig
1.Safe and stable travelling system
2.Centralized operating system
3.Powerful feeding and rotating system
4.ISO9001.2000
technic parameter
KW10 |
KW20 |
||
Total weight(Kg) |
6000 |
7500 |
|
size(mm) |
6000×2300×2500 |
5100×2300×2850 |
|
Travel speed(Km/h) |
0~2.5 |
0~2.5 |
|
Drive type |
YC4D08 |
YC6B125-K10 |
|
Drive parameter |
58Kw/2400rpm |
92Kw/2200rpm |
|
Ground clearance(mm) |
245 |
280 |
|
journey(mm) |
460 |
1000 |
|
hammer |
KXD360(KXD380) |
KXD360(KXD380) |
|
Climb slope ability( °) |
25 |
25 |
|
Drill depth(m) |
120 |
200 |
|
Work wind pressure(MPa) |
1.05-2.46 |
1.05-2.46 |
|
Air consumption(m3/min) |
16-30 |
16-30 |
|
Drill rod(mm) |
φ76,φ89 |
φ76,φ89 |
|
Drill rod length(mm) |
3000 |
3000 |
|
Drill hole diameter(mm) |
φ115-254 |
φ115-254 |
|
Push journey(mm) |
1750 |
2400 |
|
propulsion(N) |
30000 |
45000 |
|
Lifting Power(N) |
70000 |
95000 |
|
Spindle Rotary Speed(rpm) |
slow |
50 |
60 |
fast |
100 |
105 |
|
Swing torque(N·m) |
3200 |
4000 |
|
