TY-700 Vertical Injection Molding Machine

TY-700 Vertical Injection Molding Machine thumbnail-1
TY-700 Vertical Injection Molding Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, injection molding machine
Style:
Vertical
Contact Supplier Request Quote Chat Now
Hangzhou Tayu Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANG HAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, injection molding machine
Style Vertical
Brand Name TAYU
Model Number TY-700
Place of Origin Zhejiang, China
Plastic Type Thermoplastic
Automatic Other, semi auto
Injection Weight 162g, 222g
Injection Rate 87, 119 cm3/s
Clamping Force 70 ton
Opening Stroke 250
Certification ce



TY-700 Vertical Injection Molding Machine





                                                            Specification

                      Model TY700           Units Data
         Screw Diameter mm 36 42
         Injection Pressure  Kg/cm2 1723 1266
         Theoretical Shot volume cm3 182 249
         Max. Shot Weight g/Oz 162/5.7 222/7.8
         Injection Rate cm3/sec 87 119
         Temperature Control ZONE 4
         Material Hopper Capacity L 30
         Clamping Force  T 70
         Opening Force T 13.5
         Distance Between Tie Bar  mm 500x340
         Min Mold Height  mm 200
         Opening Stroke  mm 250
         Max. Open Daylight  mm 450
         Nozzle Center Height mm -
         Nozzle Center Distance  mm -
         Ejector Force  T 2.7
         Ejector Stroke  mm 50



       Slide Plate Size  mm -
       Slide Plate Stroke   mm -
       Round Set Diameter mm -
         Max. Hydraulic Pressure  Kg/cm2 140
         Pump Output  L 230
         Pump Motor Power  Kw 7.5
         Barrel Heating Power  Kw 4.5
         Total Wattage  Kw 12
         Machine Weight      T 2.8
         Machine Dimension (LxWxH)   m  2.0x1.135x2.8





Sample:

TY-700 Vertical Injection Molding MachineTY-700 Vertical Injection Molding Machine



TY-700 Vertical Injection Molding Machine



TY-700 Vertical Injection Molding Machine



Package:

TY-700 Vertical Injection Molding Machine



Exhibition:

TY-700 Vertical Injection Molding Machine
