TK-1600S Vertical Plastic Injection Machine
US$ 50,000 - 850,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rubber Injection Machine
Place of Origin:
Zhejiang, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TK-550S.BMC Vertical Injection Molding MachineNegotiableMOQ: 1 Piece -
TK400.BMC Vertical Injection Molding MachineNegotiableMOQ: 1 Piece
-
TK-1200 Vertical Injection Molding MachineNegotiableMOQ: 1 Piece
-
TK-1000FLJ.J Vertical Injection Moulding MachineNegotiableMOQ: 1 Piece
-
TK-1500S.Gvertical Injection Moulding MachineNegotiableMOQ: 1 Set
Condition
New
Type
Rubber Injection Machine
Place of Origin
Zhejiang, China
Brand Name
TAYU
Model Number
TK1600S
Voltage
220V ,380V, 415V
Power(W)
20KW
Dimension(L*W*H)
4.2x1.1x2.9
Weight
7.4T
Certification
CE
Warranty
365DAYS
After-sales Service Provided
Overseas service center available
Vertical-type four-column mould clamping, vertical-type injection, mould-clamping force of 40t, ejection volume of 86g to 109, Chinese/English electrical control, screen display, effective, fast and stable hydraulic system, reasonable mechanical structures, convenient operation, auto(motor) parts, suitable for the production of second compacting products such as electric and electronic products.
THE MACHINE PACKAGE
| Specification | |||
| Model | Units | TK1600S | |
| Screw Diameter | mm | 50 | |
| Injection Pressure | Kg/cm2 | 1856 | |
| Theoretical Shot volume | cm3 | 471 | |
| Max. Shot Weight | g/Oz | 420/14.8 | |
| Injection Rate | cm3/s | 157 | |
| Injection speed | mm/s | 80 | |
| Temperature control | Zone | 4 | |
| Material Hopper Capacity | L | 60 | |
| Clamping Force | T | 155 | |
| Opening Force | T | 7.25 | |
| Distance Between Tie Bare | mm | 650X340 | |
| Min Mold Height | mm | 300 | |
| Opening Stroke | mm | 350 | |
| Max. Open Daylight | mm | 350 | |
| Nozzle Center Height | mm | 180±50 | |
| Nozzle Center Distance | mm | 160 | |
| Ejector Force | T | - | |
| Ejector stoke | mm | - | |
| Slide Plater Size | mm | 635x540 | |
| Slide Plater Stoke | mm | 540 | |
| Round Set Diamter | mm | - | |
| Max. Hydaulic Pressure | Kg/cm2 | 140 | |
| Pump Output | L | 600 | |
| Pump Motor Power | Kw | 45 | |
| Barrel Heating Power | Kw | 12.6 | |
| Total Wattage | Kw | 57.6 | |
| Machine Weight | T | 7.4 | |
| Machine Dimensions(LxWxH) | m | 4.2x1.1x2.9 | |
