TK-550S.BMC Vertical Injection Molding Machine
- 1000 Piece / Pieces per Month
- SHANGHAI&NINGBO
- T/T
Product Details
Condition: | New | Type: | Rubber Injection Machine | Place of Origin: | Zhejiang, China |
Brand Name: | TAYU | Model Number: | TK-550S.BMC | Dimension(L*W*H): | 3.0x1.2x2.4 |
Weight: | 2.9T | Certification: | CE | Warranty: | 365 Days |
After-sales Service Provided: | Overseas service center available |
Product Description
The following materials are suitable for our products:GPPS, HIPS, SAN, ABS,LDPE, HDPE,PP, PPO, PA6, PA66, ACEAL COPOLYMER, CAB, PET, PBT,PC, PMMA, hard PVC, soft PVC,PU, EVA, PSF, Bakelite, BMC.
Tayu BMC series injection Molding machine is forming BMC (Bulk Molding come) plastic products of special injection Molding machine. Special unsaturated polyester BMC is thermosetting sclerosing resin, molding products with good electrical insulation properties, heat resistance, flame resistance, corrosion resistance, high mechanical strength, dimensional stability, small shrinkage rate, can be used to produce heavy wall products, widely used in the electronics industry, household appliances, transportation, industry, and other parts, etc. Tayu special BMC series injection molding machine, the unique design, reliable performance, accurate closed-loop control, suitable for all kinds of BMC molding of products.
Specification | ||||
Model | Units | TK550S.BMC | ||
Screw Diameter | mm | Φ36 | ||
Injection Pressure | Kg/cm2 | 1209 | ||
Theoretical Shot volume | cm3 | 152.6 | ||
Injection Rate | cm3/sec | 90.6 | ||
Injection Speed | mm/s | 89 | ||
Material Hopper Capacity | cm3 | 10 | ||
Clamping Force | T | 55 | ||
Opening Force | T | 8.3 | ||
Min Mold Height | mm | 250 | ||
Opening Stroke | mm | 200 | ||
Max. Open Daylight | mm | 450 | ||
Distance Between Tie Bare | mm | - | ||
Round Set Diamter | mm | φ900 | ||
Nozzle Center Height | mm | 150-200 | ||
Nozzle Center Distance | mm | 75 | ||
Ejector Force | T | 1.3 | ||
Ejector stoke | mm | 40 | ||
Max. Hydaulic Pressure | Kg/cm2 | 140 | ||
Pump Output | L | 160 | ||
Pump Motor Power | Kw | 7.5 | ||
Barrel Heating Power | Kw | - | ||
Total Wattage | Kw | 7.5 | ||
Machine Weight | T | 2.9 | ||
Machine Dimensions(LxWxH) | m | 3.0x1.2x2.4 |
