YTC Explosion Proof pneumatic Convertor YT-940
Product introduction
YT940 IP Converter accurately provides equipments with relevant air pressure, according to input signal of 4~20mA being delivered from the controller.
- High accuracy and reliability - Simple zero and span adjustment
- Feedback Signal (Option)
- Analog PID Control
- Tubeless connection of YT-200, Air Regulator
- Explosion Proof
The basic technical parameters
Item.Type |
YT-930 |
|
Input Signal |
4-20mA DC |
|
Output Signal |
Standard |
0.02-0.1Mpa(0.2-1.0bar) |
Multirange |
0-0.12Mpa(0-1.2bar) |
|
0.04-0.2Mpa(0.4-2.0bar) | ||
0-0.23Mpa(0-2.3bar) | ||
Supply Pressure |
Standard |
0.12-0.16MPa(1.2-1.6bar) |
Minimum |
0.2 bar graeter than the maximum calibrated output pressure |
|
Maximum |
0.24Mpa(2.4bar) |
|
Explosion Proof |
II2G Ex d IIC T6/T5 II 2D Ex tb IIIC T85℃/T100℃ |
|
Air Consumption |
Below 2LPM(sup=0.14Mpa) |
|
Flow Capacity |
70LPM(sup=0.14MPa) |
|
Repeatability |
±0.3% F.S |
|
Explosion Temp |
(-40-85℃ T5)/ (-40-75℃ T6) |
|
Operating Temp |
(-30-85℃)/(-22-185°F) |
|
Hysteresis |
±0.5% F.S |
|
Sensitivity |
±0.2% F.S |
|
Linearity |
±0.5% F.S |
|
Air Connection |
(N)PT 1/4 |
|
Conduit |
PF1/2(G1/2) |
|
Protection |
IP66 |
|
Required Operating Voltage |
Min 6.0V(at 4mA) |
|
Max 7.2V(at 20mA) | ||
Material |
Aluminum Diecasting |
|
Weight |
3kg(6.61Ib) |
|
Product Photo
Term & Payment :
1. Payment: T/T in advance or PayPal, Western Union
2. Delivery time : 4-6 weeks working days after receiving payment
3. Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder
4. 7 days free replace & 1 year free repair for quality warranty
