3121/3122/3123 Insulation Tester

Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Model Number:

3121/3122/3123

Display Type:

Analogue Only

Zhejiang Sentai Electrical Apparatus Factory

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Model Number 3121/3122/3123

Display Type Analogue Only

Measuring Range 0~2000M/1000~100000M, 0~5000M/2000~200000M......

Accuracy Class ±5% arc

Operating Temperature 0~40, 25%-80%RH

Dimensions 200*140*80mm

Specifications

3121/3122/3123 Insulation tester
Rated voltage:1000V/2500V/5000V
Resistance(ohm):0~2000M/1000~100000M, 0~5000M/2000~200000M...

3121/3122/3123 Insulation tester

Specification

3121/3122/3123 MAIN SPECIFICATION

	3121	3122	3123
Rated voltage	2500V	5000V	5000V	1000V
Resistance	02000MΩ/ 1000100000MΩ (automatic change)	05000MΩ/ 2000200000MΩ (automatic change)	05GΩ/ 2200GΩ (automatic change)	010GΩ/ 4400GΩ (automatic change)
Accuracy	±5% arc
Out voltage	±10% rated
Other function	Battery check
Dimension	200×140×80mm
Weight	1kgincluding batteries & line probe
Operating conditions	040 ,25%-80%RH
Power source	1.5V(R6) 8 pcs
Accessories	Test leads , Hard carrying case
Packaging parameters
QTY	6 pcs		G.W./N.W.	15.5/14.5kg
MEAS	62.5×34.5×33.5cm
Packaging style	Color box (default)
