Specifications
Strobe led bulb1. 30w cree Strobe led Auto bulb
2. 340 degree view angle ,red
3. dual mode constant on and strobe mode
Key specifications:
1- dual mode constant on and strobe mode,2- strobe mode = 100ms on/off duty cycle for 3000ms, off for 1000ms, return to strobe mode, repeat until power is removed.
2- constant on the first time power is applied after 2 minutes in off mode.
3- operate 8 continuous hours in constant on mode
4- operate 12 continuous hours in strobe mode
5- Must be able to switch between modes at any time.
6- operating voltage range 10-30v
7- Maximum length 52mm.
Product Description
Note on Approval: This bulb is a replacement bulb for nav lights only with the added strobe safety feature to be used at the pilot's discretion during daylight operation. Night operation requires steady on. They are not approved as a replacement for an anti-collision or strobe system. Not FAA Approved. PMA Pending.
Meets FAA AC No: 20-74 requirement.
These bulbs are standard parts and have been designed to meet the requirements of TSO-C30c.
Emitter Type: Green Cree LED's
Why choose our products ? | |
High quality |
promise to provide you the best quality products ! We check the quality of the goods one by one before shipping out , Ensure the defective rate is 0% ! |
Longer warranty period |
We warrant 2 years directly ! If there is any problem with our products (no-human damage) , we can replace a bran-new one in the new order . |
Lower price |
Much more competitive price but high quality product ! |
Fast delivery |
3~5 working days after receive the payment . |
Payment |
Paypal, T/T, Weston Union |
OEM servise |
OEM service is available ! Custom design is welcome ! |
1) Profession: more than five year's experience in madding this item led
2) Reliability: all the products were tasted by our experts; 12 months warranty
3) Information: provide customers the latest and most professional information
4) After service: solve the customers' questions at the first time
Do I use the existing wing tip red and green lenses or do I need to change to clear lenses when replacing the nag lights with LED red and green assay's?
The red and green LED nav strobes lights must be used with clear lenses to meet FAA requirements.
Turn on first: Constant lighting / Turn on second time <3s: Fast Strobe. Switch between modes in fog/cloud etc Meets FAA AC No: 20-74 requirement
Meets TC Part V - Chapter 523, Subchapter F, 523-VLA.1393
Emitter Type: Green Cree LED's
- Total Emitters: 10 x 3w
- Power: 30W
- Color BIN: Green
- Rated Voltage: 10-30VDC
- Luminous Flux: 272.5LM/21.8cdl (-10 degrees), 1020LM/81.6cdl (90 degrees)
- Color Temperature: 520-530k
- 2 modes: constant & fast strobe
- Base Type: BAY15s = Single contact and offset pin. (A-1512)
- Application: Wingtip Navigation Light replacement.
- Contains 1 light bulb per pack
Dimensions: 2.0 in x 0.7 in (52 mm x 1.8 cm)
Weight: 0.32 oz (9 g)
Turn on first: Constant lighting / Turn on second time <3s: Fast Strobe. Switch between modes in fog/cloud etc.
