Help Center5.8GHz Wlan Wifi Patch Panel Antenna TDJ-5800BP30VH14
Related Products
-
5.8G 32dBi Outdoor Parabolic AntennaUS$ 0.01 - 0.1MOQ: 2 Pieces -
0.9m 5.8G Directional Point to Point Parabolic AntennaTDJ5800D9US$ 0.01 - 0.1MOQ: 2 Pieces
-
5.8G 32dBi Outdoor Directional Parabolic Antenna TDJ5800D9US$ 0.01 - 0.1MOQ: 2 Pieces
-
Factory Price 5.8G 8dBi Fiberglass Antenna TQJ-5800AT8US$ 0.01 - 0.1MOQ: 2 Pieces
-
Factory Price 5.8G 12dBi Fiberglass Antenna TQJ-5800AT12US$ 0.01 - 0.1MOQ: 2 Pieces
Application:
1,5.1GHz 5725MHz 5850MHz frequency rang
2, wifi wlan systems
3, point to point systems
Features:
1,high frequency rang and high gain
2,low VSWR ,good performance
3,small volume and easy to install
Specification:
Catcgory |
Panel Antennas |
Model |
TDJ-5800BP30VH14 |
Frequency Range-MHz |
5725~5850 |
Bandwidth-MHz |
125 |
Gain-dBi |
14 |
Horizontal Beanwidth-° |
30 |
Beamwidth-° |
60 |
F/B Ratio-dB |
≥20 |
VSWR |
≤1.5 |
Nominal Impedance-Ω |
50 |
Polarization |
Vertical and horizontal |
Maximum Power-W |
50 |
Dimensions-mm |
220X190X50 |
Weight-kg |
1.0 |
Rated Wind Velocity-m/s |
60 |
Connector |
2 X N Female |
Payment:
1,we support payment by western union , T-T , aliexpress ,and Credit card
2, 70% once order confirmation,balance 30% before shipment
Shipment:
1,We can ship goods according your requirement
2,We also support ship by DHL , UPS , TNT ,FEDEX ,EMS , China Post
Packing :
1,Packing with Export standard cartons ,
2,Using small box pack each goods ,good quality carton for outer packing
Delivery time:
1,3-5days after receiving your full payment for samples
2,Around 7-15 days after receiving your 70% advance payment for large quantities
