GSM 900/1800mhz Mobile Antenna TQC-900/1800CII
Specifications
1, GSM 900/1800mhz mobile antenna2, Gain: 7dBi
3, Long distance transmission
4, Low VSWR
GSM 900/1800mhz mobile antenna
Applications:
* Designed for the dual band mobile communication system
Features:
* High gain, Low VSWR
* Stable performance
* Small dimmension
Specifications:
| Model | TQC-900/1800CII |
|
| Frequency Range-MHz | 890-960 |
1710-1880 |
| Bandwidth-MHz | 70 |
170 |
| Gain-dBi | 7 |
|
| VSWR | ≤1.5 |
|
| Nominal Impedance -Ω | 50 |
|
| Polarization | Vertical |
|
| Maximum Power -W | 50 |
|
| Connector | SMA male or Customization |
|
| Antenna Length -cm | 40 |
|
| Weight-g | 250 |
|
