Applicaion:
1,Cover park signals ,DAS systems
2,1800MHz / 3G /PHS
3.point to point systems
Features:
1,broadband frequency rang ,cover 806MHz-2.5GHz
2,Low vswr and high gain
3,good looking and suitable for condition
Specification:
|
Model |
TDJ-2000D |
|
Frequency Range |
1710-2170-MHz |
|
Bandwidth |
460-MHz |
|
Gain-dBi |
15x2 |
|
Beamwidth-° |
H:29-38 E:25-34 |
|
F/B ratio-dB |
≥30 |
|
VSWR |
≤1.5 |
|
Polarization-° |
±45 |
|
Max power–W |
100 |
|
Nominal Impedance–Ω |
50 |
|
Lighting Protect |
DC Ground |
|
Connector |
2xN female or customized |
|
Dimension |
362x339x125-mm |
|
Radome Material |
Organic |
|
Radiator Material |
PCB, Copper |
|
Mounting |
Frame type |
|
Weight |
4-kg |
|
Operating Temperature -°C |
-40~+60 |
|
Rated Wind Velocity-m/s |
126 |
Payment:
1,we support payment by western union , T-T , aliexpress ,and Credit card
2, 70% once order confirmation,balance 30% before shipment
Shipment:
1,We can ship goods according your requirement
2,We also support ship by DHL , UPS , TNT ,FEDEX ,EMS , China Post
Packing :
1,Packing with Export standard cartons ,
2,Using small box pack each goods ,good quality carton for outer packing
Delivery time:
1,3-5days after receiving your full payment for samples
2,Around 7-15 days after receiving your 70% advance payment for large quantities
